510-6072 TRIM GP-CABPART OF 510-6086, 541-4578, 541-4584, 541-4594, 582-4190 OPERATOR AR

Group No: 510-6072
Part NumberPart NameQty
52496851 PLATE-SIDE (RH)1
8T41892 BOLT (M8X1.25X20-MM)8
5P41163 WASHER-HARD (8.8X20.5X2-MM THK)8
7X77294 WASHER (11X25X3-MM THK)3
9X20385 WASHER (7X19X2-MM THK)2
9X20416 SCREW-TRUSS HEAD (M10X1.5X20-MM)3
18582057 CLIP5
28086188 HAMMER1
20616679 CLIP (TRIM)3
513049410 COVER-CONTROL1
513251411 BRACKET1
519243512 FLOORPLATE AS1
7T1099LINK2
524968613 COVER1
545784514 COVER1
9X104615 SCREW (M4X0.7X18-MM)2
9X204416 SCREW-TRUSS HEAD (M6X1X16-MM)2
