System And Components
542-1914 VALVE GP-MAIN CONTROLPART OF 539-4729 VALVE & MTG GP-MAIN CONTROL
Group No: 542-1914
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5579337 | 1 MANIFOLD & SOLENOID GP-CONTROL (AUXILIARY 1) | 1 | |
| 5579337 | 1A MANIFOLD & SOLENOID GP-CONTROL (STICK) | 1 | |
| 5579337 | 1B MANIFOLD & SOLENOID GP-CONTROL (BUCKET) | 1 | |
| 1091393 | BOLT-SOCKET HEAD (M4X0.7X10-MM) | 8 | |
| 3623212 | VALVE GP-SOLENOID (12-VOLT) | 4 | |
| 5579339 | 2 MANIFOLD & SOLENOID GP-CONTROL (BOOM SWING) | 1 | |
| 5579351 | 3 MANIFOLD & SOLENOID GP-CONTROL (SWING) | 1 | |
| 1091393 | BOLT-SOCKET HEAD (M4X0.7X10-MM) | 12 | |
| 3623212 | VALVE GP-SOLENOID (12-VOLT) | 4 | |
| 4491636 | VALVE GP-SOLENOID (12-VOLT) | 2 | |
| 1364184 | 4 BOLT-SOCKET HEAD (M8X1.25X40-MM) | 20 | |
| 5642791 | 5 STUD (M8X1.25X94-MM) | 5 | |
| 5P7970 | 6 NUT (M8X1.25-THD) | 7 | |
| 6V5196 | 7 BOLT-SOCKET HEAD (M8X1.25X80-MM) | 10 | |
| 5674079 | 8 VALVE GP-CONTROL (TILT) | 1 | |
| 5642802 | 9 COVER AS | 1 | |
| 5328213 | 10 VALVE AS-SOLENOID (12-VOLT)(BOOM) | 1 | |
| 3931582 | COIL AS (12-VOLT) | 1 | |
| 5642799 | 11 MANIFOLD GP-CONTROL (IMPLEMENT VALVE) | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 9X7454 | SEAL-O-RING | 1 | |
| 5642804 | 12 VALVE AS-CHECK | 1 | |
| 5674084 | 13 VALVE AS-RELIEF | 2 | |
| 5629526 | 14 GASKET | 5 | |
| 5579298 | 15 VALVE AS-CONTROL (SWING) | 1 | |
| 5579299 | 16 VALVE AS-CONTROL (BOOM SWING) | 1 | |
| 5704865 | 17 VALVE AS-CONTROL (LIFT) | 1 | |
| 5579302 | 18 VALVE AS-CONTROL (TRAVEL LEFT) | 1 | |
| 5579302 | 18A VALVE AS-CONTROL (TRAVEL RIGHT) | 1 | |
| 5674081 | 19 VALVE AS-CONTROL (AUXILIARY) | 1 | |
| 5579306 | 20 VALVE AS-CONTROL (STICK) | 1 | |
| 5674082 | 21 VALVE AS-CONTROL (BUCKET) | 1 | |
| 5650000 | 22 VALVE AS-CONTROL (BYPASS) | 1 | |
| 5674083 | 23 VALVE AS-CONTROL (BOOM) | 1 | |
| 5628138 | NUT (5/16-24-THD) | 1 | |
| 5673173 | SPRING | 1 | |
| 5629524 | 24 GASKET | 3 | |
| 5629525 | 25 GASKET | 1 | |
| 5674078 | 26 MANIFOLD GP-VALVE (BLADE LOWER) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 5649999 | 27 STUD (M8X1.25X48.1-MM) | 2 | |
| 5577676 | 28 VALVE GP-PRESSURE REDUCING (MAIN CONTROL) | 1 | |
| 9S8004 | 29 PLUG (9/16-18-THD) | 10 | |
| 3J1907 | 30 SEAL-O-RING | 10 | |
| 5642807 | 31 VALVE AS-CHECK | 7 | |
| 4388465 | 32 VALVE GP-MAKEUP (SWING RIGHT) | 1 | |
| 4388465 | 32A VALVE GP-MAKEUP (SWING LEFT) | 1 | |
| 4388465 | 32B VALVE GP-MAKEUP (BOOM SWING, RIGHT) | 1 | |
| 4388465 | 32C VALVE GP-MAKEUP (BOOM SWING, LEFT) | 1 | |
| 8T7877 | SEAL-O-RING | 1 | |
| 1860913 | 33 VALVE GP-RELIEF | 3 | |
| 1857708 | 34 VALVE GP-RELIEF | 1 | |
| 5674053 | 35 VALVE AS-RELIEF | 5 | |
| 5669876 | 36 VALVE AS-RELIEF | 1 | |
| 8T7877 | SEAL-O-RING | 1 | |
| 5641385 | 37 VALVE GP-CONTROL (2ND AUXILIARY) | 1 | |
| 5641387 | 38 PLUG AS | 2 | |
| 1301676 | SEAL-O-RING | 1 | |
| 5674055 | 39 VALVE GP-RELIEF | 1 | |
| 4175438 | 40 VALVE GP-RELIEF | 1 | |
| 8T7877 | SEAL-O-RING | 1 | |
| 4834607 | KIT-SEAL | 1 | |
| 5592265 | KIT-SEAL | 1 | |
| 5641383 | KIT-FASTENER | 1 |
