System And Components
415-3757 BELT TIGHTENER GPAN ATTACHMENT
Group No: 415-3757
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M2742 | 1 PLATE-RETAINER | 1 | |
| 7E4808 | 2 PLATE | 1 | |
| 8C5238 | 3 SEAL-V-RING | 1 | |
| 8N9409 | 4 COVER | 1 | |
| 3332408 | 5 BALL BEARING | 2 | |
| 3446306 | 6 SPRING | 2 | |
| 3512196 | 7 SPACER-SPECIAL | 1 | |
| 3941200 | 8 BUSHING | 1 | |
| 4179602 | 9 ARM AS | 1 | |
| 4S5367 | 9A BUSHING AS (MOUNT) | 1 | |
| 5M7937 | DOWEL | 1 | |
| 4205331 | 10 PULLEY | 1 | |
| 4247999 | 11 BRACKET | 1 | |
| 0S1585 | 12 BOLT (1/2-13X1.5-IN) | 2 | |
| 0S1617 | 13 BOLT (5/16-18X0.75-IN) | 4 | |
| 2N8374 | 14 GASKET | 1 | |
| 3B4617 | 15 PIN-COTTER | 2 | |
| 6C3241 | 16 BOLT (1/2-13X1.5-IN) | 1 | |
| 5P8245 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5S7379 | 18 BOLT (3/8-16X0.875-IN) | 1 | |
| 6H3956 | 19 PIN | 1 | |
| 8B1419 | 20 PIN-CLEVIS | 2 | |
| 8T4896 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 9M1974 | 22 WASHER-HARD (8.8X16X2-MM THK) | 4 |
