System And Components
488-6383 BOOM GPPART OF 486-6617 BOOM AR
Group No: 488-6383
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 3B8485 | 2 ELBOW | 1 | |
| 0930357 | 3 SPACER (63X100X9-MM THK) | 1 | |
| 1661481 | 4 SHIM (2-MM THK) | 2 | |
| 1661492 | 5 SEAL-LIP TYPE | 4 | |
| 2969586 | 6 PIN AS | 1 | |
| 3247088 | 7 BOOM & BEARING AS | 1 | |
| 2397708 | 7A BUSHING | 4 | |
| 3247091 | 8 BOOM AS | 1 | |
| 3247093 | 9 PIN | 2 | |
| 3247094 | 10 PIN AS | 1 | |
| 3247096 | 11 PIN AS | 1 | |
| 3529047 | 12 PLATE | 4 | |
| 3535514 | 13 WASHER | 1 | |
| 3535515 | 14 SHIM (0.5-MM THK) | 3 | |
| 3535516 | 15 SHIM (1-MM THK) | 5 | |
| 3535517 | 16 SHIM (2-MM THK) | 4 | |
| 4687328 | 17 SHIM (1-MM THK) | 1 | |
| 0860297 | 18 WASHER (13X50X6-MM THK) | 3 | |
| 1935914 | 19 PLUG | 10 | |
| 4M5317 | 20 BUSHING-REDUCER | 1 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4136 | 22 BOLT (M10X1.5X25-MM) | 8 | |
| 8T4192 | 23 BOLT (M12X1.75X25-MM) | 3 | |
| 8T4223 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 2582111 | 25 CAP | 1 |
