System And Components
518-9073 LINES GP-FUELS/N JP51-UP; PRH1-UP
Group No: 518-9073
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0692 | 1 CLAMP AS | 6 | |
| 1081434 | GROMMET | 1 | |
| 4P0693 | 2 CLAMP AS | 2 | |
| 1081434 | GROMMET | 2 | |
| 1275447 | 3 SPACER (10.5X20X12-MM THK) | 1 | |
| 4648785 | 4 BRACKET | 1 | |
| 3098934 | 5 PLATE | 1 | |
| 3143174 | 6 BRACKET AS | 1 | |
| 3227615 | 7 HOSE AS | 1 | |
| 3243357 | 8 HOSE AS | 2 | |
| 3274448 | 9 VALVE GP-CHECK | 1 | |
| 3353732 | 10 BRACKET | 1 | |
| 3508388 | 11 SPACER (11X25X65-MM THK) | 1 | |
| 3510258 | 12 ELBOW AS | 2 | |
| 1P7625 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3527474 | 13 BRACKET | 2 | |
| 3531841 | 14 BRACKET | 2 | |
| 3532158 | 15 CLAMP AS | 1 | |
| 1081434 | GROMMET | 4 | |
| 3611997 | 16 LINE-FUEL | 1 | |
| 3699380 | 17 MANIFOLD-FUEL | 1 | |
| 3751045 | 18 ELBOW AS | 1 | |
| 6M7476 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3854555 | 19 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 4201792 | 20 VALVE GP-CHECK | 2 | |
| 5523508 | 21 HOSE & TUBE AS | 1 | |
| 5189041 | 22 TUBE AS-FUEL | 1 | |
| 5189042 | 23 TUBE AS-FUEL | 1 | |
| 5189043 | 24 TUBE AS-FUEL | 1 | |
| 5189044 | 25 TUBE AS-FUEL | 1 | |
| 5190646 | 26 BRACKET | 1 | |
| 0618248 | 27 UNION-FLARED | 1 | |
| 0908635 | 28 SPACER (11X22X5-MM THK) | 2 | |
| 0L1143 | 29 BOLT (3/8-16X2.5-IN) | 2 | |
| 1653929 | 30 BOLT (3/8-16X1.5-IN) | 1 | |
| 0L1352 | 31 BOLT (3/8-16X3.25-IN) | 2 | |
| 0S0509 | 32 BOLT (3/8-16X0.75-IN) | 2 | |
| 0L2070 | 33 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1594 | 34 BOLT (3/8-16X1-IN) | 4 | |
| 0T0065 | 35 BOLT (3/8-16X3.5-IN) | 1 | |
| 0T0573 | 36 BOLT (3/8-16X2.75-IN) | 2 | |
| 8T1890 | 37 CLIP (TAB) | 7 | |
| 1A0291 | 38 COVER-SHAFT | 1 | |
| 1A2029 | 39 BOLT (3/8-16X1.125-IN) | 3 | |
| 1A5183 | 40 BOLT (3/8-16X4.75-IN) | 4 | |
| 1C2251 | 41 BOLT (3/8-16X1.87-IN) | 4 | |
| 2264753 | 42 GASKET | 1 | |
| 2P1282 | 43 UNION | 4 | |
| 2P7213 | 44 TEE-BULKHEAD | 1 | |
| 3072673 | 45 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3537954 | 46 GROMMET | 7 | |
| 3537955 | 47 GROMMET | 1 | |
| 3849218 | 48 CONNECTOR AS | 4 | |
| 1P1376 | CONNECTOR-PORT | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 9S8752 | 49 NUT-FULL (3/8-16-THD) | 6 | |
| 4F8965 | 50 BOLT (7/16-14X1.125-IN) | 1 | |
| 4P7581 | 51 CLIP (LADDER) | 2 | |
| 5M2894 | 52 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 5P8244 | 53 WASHER-HARD (12X22.5X2.5-MM THK) | 1 | |
| 7F2050 | 55 LOCKNUT (3/4-16-THD) | 1 | |
| 7F2060 | 56 LOCKNUT (7/8-14-THD) | 4 | |
| 9X6458 | 57 WASHER-HARD (10.2X22.5X3-MM THK) | 24 | |
| 8S9191 | 58 BOLT (3/8-16X4-IN) | 1 | |
| 8T1887 | 59 CLIP (SLOT) | 1 | |
| 8T1888 | 60 CLIP (TAB) | 1 | |
| 8T1889 | 61 CLIP (SLOT) | 7 |
