System And Components
438-1612 WIRING GP-MONITOR -PAYLOADS/N D3T1-143
Group No: 438-1612
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1258534 | 1 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1935576 | 2 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2859275 | 3 BRACKET AS | 1 | |
| 5P1076 | 3A WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 3 | |
| 3856326 | 4 LIGHTING GP-SIGNAL (PAYLOAD) | 1 | |
| 4381622 | 5 HARNESS AS-MONITOR (PAYLOAD) | 1 | |
| 1935915 | 6 PLUG | 4 | |
| 2042281 | 7 STRAP-CABLE | 11 | |
| 2048000 | 8 MOUNTING-CABLE TIE | 11 | |
| 9D3768 | 9 GROMMET | 1 | |
| 8M2784 | 10 GROMMET | 1 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 11 | |
| 8T4137 | 13 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4184 | 14 BOLT (M12X1.75X45-MM) | 1 | |
| 8T4191 | 15 BOLT (M10X1.5X16-MM) | 3 | |
| 8T4956 | 16 BOLT (M12X1.75X35-MM) | 3 |
