System And Components
513-2525 AIR CONDITIONER GPPART OF 513-0499 AIR CONDITIONER & MOUNTING GP
Group No: 513-2525
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5386393 | 1 GASKET | 1 | |
| 7F2050 | 2 LOCKNUT (3/4-16-THD) | 1 | |
| 7F2060 | 3 LOCKNUT (7/8-14-THD) | 1 | |
| 7T9793 | 4 VALVE-CHECK | 4 | |
| 2098296 | 5 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 1 | |
| 3270282 | 6 SEAL-INTEGRAL (1/2-IN) | 2 | |
| 3270283 | 7 SEAL-INTEGRAL (3/4-IN) | 2 | |
| 3551790 | 8 CLAMP | 1 | |
| 4352988 | 9 CLIP AS | 2 | |
| 4491706 | 10 SCREW-PAN HEAD (8-16X0.75-IN) | 49 | |
| 4769504 | 11 SENSOR (TEMPERATURE) | 1 | |
| 5254852 | 12 CLIP | 2 | |
| 5502025 | 13 GROMMET | 1 | |
| 2H3922 | 14 LOCKWASHER | 1 | |
| 2H3923 | 15 LOCKWASHER | 1 | |
| 5386378 | 16 CASE (LOWER) | 1 | |
| 5386379 | 17 CASE (UPPER) | 1 | |
| 5386380 | 18 PLATE-SUPPORT | 1 | |
| 5386381 | 19 CASE (AIR INLET) | 1 | |
| 5386382 | 20 COVER-AIR INLET | 1 | |
| 5386383 | 21 BAFFLE (AIR) | 1 | |
| 5386384 | 22 BLOWER AS | 1 | |
| 5386385 | 23 EVAPORATOR AS | 1 | |
| 5386387 | 24 GROMMET | 1 | |
| 5386388 | 25 GROMMET | 1 | |
| 5386392 | 26 CORE AS-HEATER | 1 | |
| 5386394 | 27 GASKET | 1 | |
| 5386396 | 28 FILTER | 1 | |
| 5386397 | 29 GASKET | 1 | |
| 5386398 | 30 GASKET | 2 | |
| 5386400 | 31 GROMMET (HEATER) | 1 | |
| 5386401 | 32 GASKET (FLOOR) | 1 | |
| 5386402 | 33 GASKET (AIR INLET) | 1 | |
| 5386403 | 34 GASKET-DUCT | 1 | |
| 5386404 | 35 GASKET-DUCT | 1 | |
| 5386406 | 36 BRACKET-SUPPORT | 1 | |
| 5386411 | 37 HOSE AS | 1 | |
| 5386412 | 38 HOSE AS | 1 | |
| 5386414 | 39 GASKET (BULKHEAD) | 1 | |
| 5386415 | 40 BULKHEAD AS | 1 | |
| 5528909 | 41 VALVE AS-EXPANSION | 1 | |
| 5642796 | 42 THERMOSTAT | 1 | |
| 5C9553 | 43 BOLT (M6X1X16-MM) | 1 | |
| 6V8653 | 44 BOLT-SOCKET HEAD (M6X1X40-MM) | 2 | |
| 8T0154 | 45 CLAMP-HOSE | 4 | |
| 8T4224 | 46 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 1361953 | 47 HOSE (51.1-CM) | ||
| 1361953 | 47A HOSE (43.4-CM) |
