System And Components
440-2742 LINES GP-PILOT -MAIN CONTROL VALVES/N PC81-UP
Group No: 440-2742
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I9521 | 1 BAND-MARKER (RED, L1) | 1 | |
| 4I9522 | 2 BAND-MARKER (YELLOW, L2) | 1 | |
| 4I9523 | 3 BAND-MARKER (BLUE, L3) | 1 | |
| 4I9524 | 4 BAND-MARKER (BROWN, L4) | 1 | |
| 4I9525 | 5 BAND-MARKER (ORANGE, R1) | 1 | |
| 4I9526 | 6 BAND-MARKER (WHITE, R2) | 1 | |
| 4I9527 | 7 BAND-MARKER (GREEN, R3) | 1 | |
| 4I9528 | 8 BAND-MARKER (PURPLE, R4) | 1 | |
| 7K1181 | 9 STRAP-CABLE | 5 | |
| 1110976 | 10 HOSE AS | 1 | |
| 1360207 | 11 STRAP-CABLE (BLACK) | 3 | |
| 1488424 | 12 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T8902 | ADAPTER-TEE | 1 | |
| 1645628 | 13 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1076631 | CONNECTOR-FILTER | 1 | |
| 2226869 | 14 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 9X2614 | CONNECTOR | 1 | |
| 2376094 | 15 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 2376095 | CONNECTOR | 1 | |
| 2794731 | 16 STRAP-CABLE (RED) | 1 | |
| 2794732 | 17 STRAP-CABLE (YELLOW) | 1 | |
| 2794735 | 18 STRAP-CABLE (ORANGE) | 1 | |
| 8L8413 | 19 STRAP-CABLE (WHITE) | 1 | |
| 2852715 | 20 HOSE AS | 2 | |
| 3057800 | 21 HOSE AS | 1 | |
| 3057813 | 22 HOSE AS | 1 | |
| 3073404 | 23 HOSE AS | 1 | |
| 3079017 | 24 HOSE AS | 1 | |
| 3084073 | 25 HOSE AS | 1 | |
| 3084075 | 26 HOSE AS | 2 | |
| 3132280 | 27 HOSE AS | 1 | |
| 3279619 | 28 GUIDE | 1 | |
| 4709724 | 29 HOSE AS | 1 | |
| 3491812 | 30 SWITCH AS-PRESSURE (PILOT OIL) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1087516 | FITTING | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 3790535 | 31 HOSE AS | 1 | |
| 4171100 | 32 VALVE GP-PILOT (SHUTTLE) | 1 | |
| 4388378 | 33 VALVE GP-MANIFOLD & REDUCING | 1 | |
| 4439850 | 34 PLATE AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 4439852 | 35 HOSE AS | 1 | |
| 4567218 | 36 VALVE GP-REDUCING (BOOM DOWN) | 1 | |
| 4567219 | 37 VALVE GP-REDUCING (STICK OUT) | 1 | |
| 4606533 | 38 HOSE AS | 1 | |
| 4606534 | 39 HOSE AS | 1 | |
| 4606537 | 40 HOSE AS | 1 | |
| 4606539 | 41 HOSE AS | 1 | |
| 1488336 | 42 CONNECTOR AS | 7 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488353 | 43 ELBOW AS | 10 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488378 | 44 ELBOW AS | 7 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488407 | 45 PLUG AS | 6 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1503065 | 46 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V0484 | ELBOW | 1 | |
| 1654931 | 47 ELBOW AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8077 | ELBOW | 1 | |
| 1904885 | 48 SPACER (11X22X50-MM THK) | 1 | |
| 3J1907 | 49 SEAL-O-RING | 2 | |
| 6V8397 | 50 SEAL-O-RING | 2 | |
| 8T3647 | 51 BOLT (M8X1.25X80-MM) | 4 | |
| 8T4121 | 52 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4136 | 53 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4172 | 54 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4224 | 55 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 1344540 | 56 SLEEVE-HOSE (30-CM) |
