423-4018 RADIATOR & HYD OIL COOLER GPS/N DTG1-UP

Group No: 423-4018

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	3
5D8159	2 PIN AS	4
0964035	3 CLIP	3
3133762	4 CUSHION-RUBBER	2
3133766	5 SLEEVE	2
3133769	6 CUSHION-RUBBER	2
3146506	7 CUSHION-RUBBER	2
3477620	8 MOUNT	2
3527775	9 SEAL	2
3535558	10 SCREEN AS (RADIATOR)	1
3535559	11 SCREEN AS (HYDRAULIC OIL COOLER)	1
3550452	12 SEAL-AIR	2
3774993	13 BRACKET AS	1
4160965	14 CAP-RADIATOR	1
4186597	15 SWITCH GP-LIQUID LEVEL (OIL)	1
1028802	KIT-RECEPTACLE (2-PIN)	1
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	2
4226993	16 PLATE AS	2
4226994	17 BRACKET AS	2
4226996	18 BRACKET AS	1
4234019	19 CORE AS-RADIATOR	1
3324192	SEAL-O-RING	1
3550468	PLUG-DRAIN	1
4234020	20 SHROUD AS	1
4414594	21 SEAL-AIR	1
4414595	22 SEAL-AIR	1
4468479	23 SEAL-AIR	4
4530622	24 FRAME AS	1
4530625	25 CORE AS-AFTERCOOLER	1
5M6213	PLUG-PIPE (1/4-18-THD)	1
4530626	26 PLATE AS	1
4530627	27 PLATE AS	1
4530628	28 SEAL-AIR	4
4530629	29 SEAL-AIR	1
4530630	30 SEAL-AIR	1
4530631	31 SEAL-AIR	2
4813473	32 CORE AS-OIL COOLER (HYDRAULIC)	1
4813474	33 SEAL-AIR	3
1156433	34 WASHER (11X50X6-MM THK)	2
1343196	35 WASHER (10.2X39.6X2.3-MM THK)	4
1549023	36 VALVE-SAMPLING	1
1570670	37 CAP-DUST	1
2M9780	38 SEAL-O-RING	1
5P1076	39 WASHER-HARD (13.5X30X4-MM THK)	2
6V9027	40 SEAL-O-RING	1
7X7729	41 WASHER (11X25X3-MM THK)	12
8T4121	42 WASHER-HARD (11X21X2.5-MM THK)	12
8T4136	43 BOLT (M10X1.5X25-MM)	24
8T4139	44 BOLT (M12X1.75X30-MM)	2
8T4186	45 BOLT (M10X1.5X40-MM)	4
8T4189	46 BOLT (M8X1.25X20-MM)	8
8T4195	47 BOLT (M10X1.5X30-MM)	2
8T4224	48 WASHER-HARD (8.8X16X2-MM THK)	8
7Y1976	49 HOSE-WATER (150-CM)
7Y1976	49A HOSE-WATER (20-CM)
