System And Components
7C-8433 COMPRESSOR GP-REFRIGERANTS/N 9XG1-UP
Group No: 7C-8433 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T2502 | 1 BOLT (3/8-16X1.125-IN) | 2 | |
| 8T4896 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 7W4975 | 3 STRAP | 1 | |
| 8T4835 | 4 BOLT (1/2-13X2-IN) | 1 | |
| 8F0492 | SPACER (0.531X1.125X0.625-IN THK) | 1 | |
| 8T4223 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 7C8236 | 6 V-BELT | 1 | |
| 8T9389 | 7 BOLT (1/2-13X2.75-IN) | 1 | |
| 6V8188 | 8 NUT (1/2-13-THD) | 2 | |
| 5S7383 | 9 BOLT (3/8-16X1.75-IN) | 2 | |
| 7W4973 | 10 BRACKET | 1 | |
| 6V4432 | 11 BOLT (1/2-13X4-IN) | 1 | |
| 7W4974 | 12 PLATE | 2 | |
| 4L9337 | 13 BOLT (3/8-16X1.5-IN) | 6 | |
| 7T8600 | 14 COMPRESSOR GP-REFRIGERANT | 1 | |
| 7C8434 | 15 BRACKET | 1 | |
| 9G9150 | 16 CLIP | 1 | |
| 6V8801 | 17 NUT (3/8-16-THD) | 7 | |
| 7W4978 | 18 NUT AS | 1 |
