6C-8277 GUARD GP-OVERHEADS/N 6XK1-UP

Group No: 6C-8277
Part NumberPart NameQty
6C82171 GUARD AS1
6C82182 GUARD AS1
6C82293 SUPPORT AS1
9X82574 WASHER (17.5X30X3.5-MM THK)8
7X25535 BOLT (M16X2X40-MM)4
7F90906 SCREW-DRIVE (NO 8X3/8-IN)4
10442577 PLATE-WARNING1
8T63838 BOLT (M16X2X200-MM)4
6C83819 SPRING-GAS2
5G081710 BUMPER-CONICAL2
4F229411 NUT-JAM (5/16-24-THD)2
5P107512 WASHER-HARD (10.2X22.5X3-MM THK)2
9V478613 CLIP4
4M528014 NUT-PLATED FULL (5/16-18-THD)4
9V478715 STUD-BALL4
5C726116 NUT (M8X1.25-THD)2
8T686917 BOLT (M8X1.25X60-MM)2
6C837818 BRACKET AS (LH)1
6C837319 BRACKET AS (RH)1
9X825720 WASHER (17.5X30X3.5-MM THK)8
096488521 LOCKNUT (M16X2-THD)2
8T417422 BOLT (M16X2X120-MM)2
4H162123 BLOCK-MOUNTING2
8T419324 BOLT (M16X2X50-MM)4
6C838225 SPRING-LATCH2
6C837926 LATCH AS2
