System And Components
126-3162 GUARD GP-OVERHEADS/N 9FL1-UP
Group No: 126-3162
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1229719 | 1 GUARD AS-FRONT | 1 | |
| 1238305 | 2 GUARD AS-TOP | 1 | |
| 6C8229 | 3 SUPPORT AS | 1 | |
| 9X8257 | 4 WASHER (17.5X30X3.5-MM THK) | 16 | |
| 7X2553 | 5 BOLT (M16X2X40-MM) | 2 | |
| 9X8937 | 6 TACK | 8 | |
| 8T6383 | 7 BOLT (M16X2X200-MM) | 4 | |
| 1151624 | 8 SPRING AS-GAS | 2 | |
| 4E1384 | 9 BUMPER-CONICAL | 2 | |
| 8T4224 | 10 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4897 | 11 WASHER (10.2X35X6-MM THK) | 2 | |
| 8T4174 | 12 BOLT (M16X2X120-MM) | 2 | |
| 0964885 | 13 LOCKNUT (M16X2-THD) | 2 | |
| 1379412 | 14 BLOCK-MOUNTING | 2 | |
| 6C8373 | 15 BRACKET AS (RH) | 1 | |
| 6C8378 | 16 BRACKET AS (LH) | 1 | |
| 6C8379 | 17 LATCH AS | 2 | |
| 6C8382 | 18 SPRING-LATCH | 2 | |
| 8T4193 | 19 BOLT (M16X2X50-MM) | 6 | |
| 8T6869 | 20 BOLT (M8X1.25X60-MM) | 2 | |
| 5C7261 | 21 NUT (M8X1.25-THD) | 8 | |
| 1248758 | 22 PLATE-WARNING (FRONT GUARD) | 1 | |
| 6C4000 | 23 SHIM (1-MM THK) | 8 | |
| 1532524 | 24 LAMP GP-FLOOD (24-VOLT) | 2 | |
| 1177029 | 25 HARNESS AS | 1 | |
| 0138502 | 26 LOCKWASHER | 2 | |
| 2B8352 | 27 WASHER (CONICAL) | 4 | |
| 6C9134 | 28 HARNESS AS | 1 | |
| 1248759 | 29 PLATE-WARNING (TOP GUARD) | 1 | |
| 1436410 | 30 PLATE-ROPS (FRONT GUARD) | 1 | |
| 1436423 | 31 PLATE-ROPS (TOP GUARD) | 1 |
