Assembly
100%

4Q-4493 GUARD GP-OVERHEADS/N 3YR1-UP; 5LR1-UP

Group No: 4Q-4493
Part NumberPart NameQty
12297191 GUARD AS-FRONT1
13069632 GUARD AS1
14904683 SUPPORT AS1
9X82574 WASHER (17.5X30X3.5-MM THK)16
8T63835 BOLT (M16X2X200-MM)4
7X25536 BOLT (M16X2X40-MM)2
11516248 SPRING AS-GAS2
4E13849 BUMPER-CONICAL2
8T422410 WASHER-HARD (8.8X16X2-MM THK)2
8T489711 WASHER (10.2X35X6-MM THK)2
8T417412 BOLT (M16X2X120-MM)2
096488513 LOCKNUT (M16X2-THD)2
137941214 BLOCK-MOUNTING2
6C837315 BRACKET AS1
6C837816 BRACKET AS1
9V478617 CLIP4
9V478718 STUD-BALL4
4M528019 NUT-PLATED FULL (5/16-18-THD)4
6C837920 LATCH AS2
6C838221 SPRING-LATCH2
8T419322 BOLT (M16X2X50-MM)6
8T686923 BOLT (M8X1.25X60-MM)2
5C726124 NUT (M8X1.25-THD)4
6C400026 SHIM (1-MM THK)8
153252427 LAMP GP-FLOOD (24-VOLT)2
152081828 HARNESS AS1
013850229 LOCKWASHER2
2B835230 WASHER (CONICAL)4
6C913431 HARNESS AS1
