System And Components
6C-8277 GUARD GP-OVERHEADS/N 9FS1-UP; 2KW1-UP; 6SW1-UP; 9NW1-UP
Group No: 6C-8277
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1229719 | 1 GUARD AS-FRONT | 1 | |
| 1238305 | 2 GUARD AS-TOP | 1 | |
| 6C8229 | 3 SUPPORT AS | 1 | |
| 9X8257 | 4 WASHER (17.5X30X3.5-MM THK) | 16 | |
| 7X2553 | 5 BOLT (M16X2X40-MM) | 2 | |
| 8T9530 | 6 TACK (METAL) | 8 | |
| 8T6383 | 7 BOLT (M16X2X200-MM) | 4 | |
| 6C8382 | 8 SPRING-LATCH | 2 | |
| 4E1384 | 9 BUMPER-CONICAL | 2 | |
| 8T4224 | 10 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4897 | 11 WASHER (10.2X35X6-MM THK) | 2 | |
| 8T4174 | 12 BOLT (M16X2X120-MM) | 2 | |
| 0964885 | 13 LOCKNUT (M16X2-THD) | 2 | |
| 1379412 | 14 BLOCK-MOUNTING | 2 | |
| 6C8373 | 15 BRACKET AS (RH) | 1 | |
| 6C8378 | 16 BRACKET AS (LH) | 1 | |
| 9V4786 | 17 CLIP | 4 | |
| 9V4787 | 18 STUD-BALL | 4 | |
| 4M5280 | 19 NUT-PLATED FULL (5/16-18-THD) | 4 | |
| 6C8379 | 20 LATCH AS | 2 | |
| 1151624 | 21 SPRING AS-GAS | 2 | |
| 8T4193 | 22 BOLT (M16X2X50-MM) | 6 | |
| 8T6869 | 23 BOLT (M8X1.25X60-MM) | 2 | |
| 5C7261 | 24 NUT (M8X1.25-THD) | 4 | |
| 1248759 | 25 PLATE-WARNING (TOP GUARD) | 1 | |
| 6C4000 | 26 SHIM (1-MM THK) | 8 | |
| 1248758 | 27 PLATE-WARNING (FRONT GUARD) | 1 |
