System And Components
192-3663 LINES GP-BOOM CYLINDERS/N 9WW1-UP; 6DZ1-UP
Group No: 192-3663
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0931300 | 1 CLAMP | 2 | |
| 1053483 | 2 BOLT-SOCKET HEAD (M10X1.5X70-MM) | 4 | |
| 1845202 | 3 VALVE GP-LOAD CONTROL | 1 | |
| 1943651 | 4 TUBE AS | 1 | |
| 1943653 | 5 TUBE AS | 1 | |
| 1943656 | 6 SUPPORT AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1P3703 | 7 SEAL-RECTANGULAR | 2 | |
| 4J5267 | 8 SEAL-O-RING | 1 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4185 | 10 BOLT (M10X1.5X50-MM) | 8 | |
| 8T4194 | 11 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4196 | 12 BOLT (M10X1.5X35-MM) | 2 |
