System And Components
153-2912 CAB GPS/N FDL1-UP; CLS1-UP
Group No: 153-2912
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1551201 | 2 DOOR | 1 | |
| 5C9553 | 3 BOLT (M6X1X16-MM) | 10 | |
| 6C9130 | 4 WASHER (6X18X1-MM THK) | 17 | |
| 6W8906 | 5 LATCH AS | 1 | |
| 6C9224 | 6 SCREW | 2 | |
| 1088839 | 7 SUPPORT-FILTER | 1 | |
| 1335514 | 8 HAMMER | 1 | |
| 6C9226 | 9 FILTER ELEMENT-CAB AIR | 1 | |
| 1565425 | 10 GLASS | 1 | |
| 1564585 | 11 GLASS | 1 | |
| 1325347 | 12 GLASS | 1 | |
| 1325097 | 13 GLASS | 1 | |
| 6C4000 | 14 SHIM (1-MM THK) | 4 | |
| 6C8970 | 15 SEAL | 1 | |
| 9X2446 | 16 FILM-IDENTIFICATION (CATERPILLAR) | 1 | |
| 6C8972 | 17 HOOK | 1 | |
| 6C9087 | 18 WASHER | 12 | |
| 1551202 | 19 LINER | 1 | |
| 1551203 | 20 LINER | 1 | |
| 1565426 | 21 LINER | 1 | |
| 1351619 | 22 LINER | 1 | |
| 6C8980 | 23 NOZZLE-AIR | 6 | |
| 6V7357 | 24 BOLT (M6X1X25-MM) | 4 | |
| 1095008 | 25 BUMPER-CONICAL | 1 | |
| 1337514 | 26 LINER | 1 | |
| 8T4157 | 27 STRIKER AS | 1 | |
| 6C9236 | 28 RETAINER | 2 | |
| 6C9237 | 29 RIVET | 2 | |
| 1258619 | 30 SCREW | 2 | |
| 6C9092 | 31 WASHER | 2 | |
| 1017396 | 32 BOLT-SOCKET HEAD (M10X1.5X50-MM) | 2 | |
| 6C9252 | 33 BOX-LOCK | 1 | |
| 8Y6380 | 34 LATCH AS | 1 | |
| 6C8986 | 35 CLIP-AXLE | 2 | |
| 8T4189 | 36 BOLT (M8X1.25X20-MM) | 4 | |
| 1644344 | 37 PLUG | 8 | |
| 1766425 | 38 COVER | 1 | |
| 1801718 | 39 NUT (M6X1-THD) | 7 | |
| 9X2044 | 40 SCREW-TRUSS HEAD (M6X1X16-MM) | 7 | |
| 1199425 | 41 GUIDE | 1 | |
| 8T4181 | 42 BOLT (M6X1X20-MM) | 2 | |
| 1766421 | 43 LEVER | 1 | |
| 6C8996 | 44 CAP | 11 | |
| 1190872 | 45 HANDLE AS | 1 | |
| 6C8998 | 46 CAP | 3 | |
| 6C9002 | 47 PLATE | 1 | |
| 6C9003 | 48 STOP | 2 | |
| 1175640 | 49 NUT (M6X1-THD) | 3 | |
| 6C9181 | 50 COVER | 1 | |
| 0950827 | 51 LOCKWASHER | 6 | |
| 5P6872 | 52 MIRROR AS | 1 | |
| 6C9132 | 53 SCREW | 2 | |
| 6C9001 | 54 CLAMP | 1 | |
| 9X8257 | 55 WASHER (17.5X30X3.5-MM THK) | 4 | |
| 6C9241 | 56 BOLT | 4 | |
| 6C9058 | 57 SCREW (M6X1X12-MM) | 8 | |
| 5C7261 | 58 NUT (M8X1.25-THD) | 8 | |
| 6C9238 | 59 NUT | 1 | |
| 6C9078 | 60 WASHER | 16 | |
| 1095005 | 61 INSULATION | 1 | |
| 1766415 | 62 HANDLE | 1 | |
| 6C9000 | 63 SUPPORT | 1 | |
| 1259158 | 65 SEAL | 1 | |
| 4E1384 | 66 BUMPER-CONICAL | 1 | |
| 1766419 | 67 SUPPORT-LINER | 1 | |
| 1565407 | 68 SUPPORT-LINER | 1 | |
| 6C9232 | 69 RIVET | 9 | |
| 6C9235 | 70 PLATE-IDENTIFICATION (CAB) | 1 | |
| 1409109 | 71 SUPPORT-GLASS | 2 | |
| 6C8584 | 72 SCREW (M6X1X8-MM) | 6 | |
| 4I5049 | 73 NUT-SPACER (M6X1-THD) | 3 | |
| 1175644 | 74 BOOT | 2 | |
| 1175645 | 75 BOLT (M6X1X20-MM) | 3 | |
| 6C8587 | 76 SEAL | 2 | |
| 6C8588 | 77 STOP | 2 | |
| 1369453 | 78 LINER | 1 | |
| 1369454 | 79 LINER | 1 | |
| 7X2552 | 80 BOLT (M16X2X30-MM) | 4 | |
| 1205737 | 81 WASHER (17.5X40X4-MM THK) | 4 | |
| 1198340 | 82 SEAL | 4 | |
| 6C3982 | 83 GUARD | 1 | |
| 1091267 | 84 WASHER | 4 | |
| 6C9089 | 85 NUT-CAP | 3 | |
| 1565405 | 86 SUPPORT | 2 | |
| 1088227 | 87 WASHER (FLAT) | 2 | |
| 9N1995 | 88 RIVET-POP | 2 | |
| 1199428 | 89 KNOB | 1 | |
| 1204831 | 90 WASHER (18.5X32X1.5-MM THK) | 1 | |
| 1544811 | 91 SPACER-SPECIAL | 1 | |
| 1198353 | 92 SCREW-SPECIAL | 1 | |
| 1544793 | 93 SPRING | 1 | |
| 1766422 | 94 ROD | 1 | |
| 5C2890 | 95 NUT (M6X1-THD) | 1 | |
| 1766418 | 96 STOP | 1 | |
| 1766417 | 97 CABLE | 1 | |
| 1766420 | 98 SUPPORT | 1 | |
| 6C9119 | 99 SCREW (M5X0.8X12-MM) | 2 | |
| 1809417 | 100 NUT | 2 | |
| 9X2480 | 101 BOLT (M6X1X45-MM) | 2 | |
| 1809418 | 102 CAP | 2 |
