Assembly
100%

169-9723 LINES GP-COUPLERS/N BNN1-UP; CBT1-UP

Group No: 169-9723
Part NumberPart NameQty
23957281 HOSE AS2
13960082 BRACKET1
13960093 BRACKET1
8T41364 BOLT (M10X1.5X25-MM)4
8T41215 WASHER-HARD (11X21X2.5-MM THK)8
6V91686 NUT (11/16-16-THD)6
14883777 ELBOW AS2
6V8397SEAL-O-RING2
6V8980ELBOW1
16997278 BRACKET1
06725519 CLIP4
169972510 HOSE AS2
169972411 HOSE AS2
8T419112 BOLT (M10X1.5X16-MM)2
169975413 LINK AS1
169975514 LINK AS1
6V982915 CAP (ORFS)2
115804516 CHANNEL1
7X257217 BOLT (M24X3X35-MM)2
8T416718 WASHER-HARD (26X44X4-MM THK)2
096487619 NUT (M14X2-THD)4
099072420 BOLT (M14X2X145-MM)2
8T413721 BOLT (M10X1.5X20-MM)4
9X202722 WASHER (11X18X2-MM THK)2
7K118123 STRAP-CABLE1
149545224 UNION AS (STRAIGHT)4
