System And Components
171-6570 LINES GP-COUPLERS/N BNN1-UP; CBT1-UP
Group No: 171-6570
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1760571 | 1 HOSE AS | 2 | |
| 6V8397 | 2 SEAL-O-RING | 12 | |
| 1396008 | 3 BRACKET | 1 | |
| 1396009 | 4 BRACKET | 1 | |
| 8T4136 | 5 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4121 | 6 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 1488377 | 7 ELBOW AS | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8980 | ELBOW | 1 | |
| 6V9168 | 8 NUT (11/16-16-THD) | 6 | |
| 1734207 | 9 HOSE AS | 2 | |
| 6V9829 | 10 CAP (ORFS) | 2 | |
| 0672551 | 11 CLIP | 4 | |
| 1158045 | 12 CHANNEL | 1 | |
| 1495452 | 13 UNION AS (STRAIGHT) | 4 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 1699727 | 14 BRACKET | 1 | |
| 8T4191 | 15 BOLT (M10X1.5X16-MM) | 2 | |
| 7X2572 | 16 BOLT (M24X3X35-MM) | 2 | |
| 8T4167 | 17 WASHER-HARD (26X44X4-MM THK) | 2 | |
| 1699724 | 18 HOSE AS | 2 | |
| 1699754 | 19 LINK AS | 1 | |
| 0990724 | 20 BOLT (M14X2X145-MM) | 2 | |
| 0964876 | 21 NUT (M14X2-THD) | 4 | |
| 1699755 | 22 LINK AS | 1 | |
| 8T4137 | 23 BOLT (M10X1.5X20-MM) | 4 | |
| 7K1181 | 24 STRAP-CABLE | 1 | |
| 9X2027 | 25 WASHER (11X18X2-MM THK) | 2 |
