Assembly
100%

164-1300 WINDOW GP-CAB -REARS/N BLD1-1594

Group No: 164-1300
Part NumberPart NameQty
11056021 KNOB2
13182032 SCREW-FLAT HEAD (M8X1.25X30-MM)4
14099213 INSERT-THREADED2
14677444 KIT-LATCH1
14677455 KIT-LATCH1
15080156 GASKET2
16413047 GLASS1
16413088 ROLLER2
16413119 LINKAGE AS1
164131710 FRAME AS1
1409921INSERT-THREADED4
164132811 SPRING AS-GAS2
164134212 BOLT-SPECIAL (M10X1.5X28-MM)4
164134313 WASHER-THRUST (13.6X30X5.1-MM THK)4
164134414 WASHER-THRUST (13.6X30X2.1-MM THK)4
164134515 BEARING4
164134616 STRIKER4
164134817 WINDOW AS1
1641303GLASS1
1641316FRAME AS1
164135118 PIN2
164135219 LATCH AS1
164135320 LATCH AS1
167818221 BUMPER2
171287022 SPACER (7X10X5.4-MM THK)2
201946523 SHIM (1-MM THK)4
205753624 BRACKET AS (LH)1
205753825 BRACKET AS (RH)1
119834926 CAP2
121974327 SEAL1
129318028 LOCKNUT (M12X1.75-THD)4
5P411529 WASHER-HARD (7.2X19X2-MM THK)6
5P411630 WASHER-HARD (8.8X20.5X2-MM THK)4
8T413831 BOLT (M6X1X20-MM)2
8T420032 BOLT (M8X1.25X16-MM)4
8T422333 WASHER-HARD (13.5X25.5X3-MM THK)4
9X204434 SCREW-TRUSS HEAD (M6X1X16-MM)4
9X213235 RETAINER4
164135436 CHANNEL-WINDOW (86.6CM)
5P563737 SEAL (0.85M)
9X638338 SEAL (85CM)
164131439 SEAL-BULK (148.5CM)2
164135440 CHANNEL-WINDOW (95.4CM)2
164135441 CHANNEL-WINDOW (50.9CM)2
