System And Components
184-9725 WIPER GP-WINDOW -UPPER & TOPS/N CCC1-UP; FEE1-UP
Group No: 184-9725
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1249271 | 1 SUPPORT AS | 1 | |
| 8T4200 | 2 BOLT (M8X1.25X16-MM) | 2 | |
| 6C9087 | 3 WASHER | 2 | |
| 6C3431 | 4 ANTENNA | 1 | |
| 1310327 | 5 CONVERTER AS (24-VOLT) | 1 | |
| 1454446 | 6 CONTROL GP-WASHER & WIPER | 1 | |
| 1310399 | 7 MOTOR AS-WINDOW WIPER (UPPER) | 1 | |
| 6C9129 | 8 BOLT (M6X1X40-MM) | 1 | |
| 1350429 | 9 LINK AS | 1 | |
| 6C9221 | 10 NUT (M24X1.5-THD) | 1 | |
| 6C9097 | 11 NUT (M16X1-THD) | 1 | |
| 6C9103 | 12 BOSS | 1 | |
| 6C9104 | 13 CAP-WIPER | 1 | |
| 5C9553 | 14 BOLT (M6X1X16-MM) | 9 | |
| 6C9130 | 15 WASHER (6X18X1-MM THK) | 13 | |
| 6C9142 | 16 BLADE AS-WIPER | 1 | |
| 5C7261 | 17 NUT (M8X1.25-THD) | 2 | |
| 6C9143 | 18 ARM AS | 1 | |
| 6C9107 | NOZZLE-WATER | 1 | |
| 6C9108 | HOSE-WATER | 1 | |
| 6C9109 | CLIP | 2 | |
| 6C9110 | ELBOW | 1 | |
| 1306568 | 19 HARNESS AS | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 4I5049 | 20 NUT-SPACER (M6X1-THD) | 3 | |
| 6C9092 | 21 WASHER | 2 | |
| 6C9125 | 22 ASHTRAY AS | 1 | |
| 1433422 | 23 HARNESS AS | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 6C9078 | 24 WASHER | 9 | |
| 2008199 | 25 HARNESS AS-CAB | 1 | |
| 9W0335 | 26 LIGHTER AS-CIGAR (24-VOLT) | 1 | |
| 0950827 | 27 LOCKWASHER | 6 | |
| 1876068 | 28 HOSE | 1 | |
| 6C9199 | 29 CAP | 1 | |
| 6C9089 | 30 NUT-CAP | 3 | |
| 2008203 | 31 NUT-SPECIAL | 3 | |
| 5C2890 | 32 NUT (M6X1-THD) | 3 | |
| 8T5400 | 33 CONNECTOR | 1 | |
| 6C9119 | 34 SCREW (M5X0.8X12-MM) | 2 | |
| 3T6655 | 35 SWITCH AS-ROTARY (WIPER, WASHER)(TOP WINDOW) | 1 | |
| 7T9302 | KNOB AS-WIPER SWITCH (WASHER) | 1 | |
| 1308110 | 36 SPACER | 2 | |
| 1091270 | 37 GROMMET | 4 | |
| 1204825 | 38 GROMMET | 2 | |
| 6C9121 | 39 BRACKET AS-LAMP | 1 | |
| 6C9122 | 40 LAMP (24-VOLT)(DOME) | 2 | |
| 1519385 | 41 MONITOR GP-OPERATOR | 1 | |
| 1712655 | COVER | 1 | |
| 1573122 | KIT-BACKUP ALARM | 1 | |
| 9W1494 | 42 KIT-SERVICE METER (24-VOLT) | 1 | |
| 2011729 | 43 COVER-MONITOR | 1 | |
| 1413980 | 44 SUPPORT AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 1123309 | 45 CLAMP | 2 | |
| 1091253 | 46 HOSE | 1 | |
| 1091254 | 47 NOZZLE-AIR | 1 | |
| 6C9058 | 48 SCREW (M6X1X12-MM) | 3 | |
| 1396039 | 49 NUT-RETAINER (U-TYPE) | 3 | |
| 9X2044 | 50 SCREW-TRUSS HEAD (M6X1X16-MM) | 5 | |
| 1409112 | 51 CLIP | 1 | |
| 5P4115 | 52 WASHER-HARD (7.2X19X2-MM THK) | 2 | |
| 1308108 | 53 CAP-SUPPORT | 1 | |
| 1245679 | 54 MOTOR GP-WINDOW WIPER (TOP) | 1 | |
| 1308109 | 55 CAP-WIPER MOTOR | 1 | |
| 1245686 | 56 ARM AS | 1 | |
| 1198344 | 57 BLADE AS-WIPER | 1 | |
| 1453706 | 58 SCREW | 3 | |
| 3S2093 | 59 STRAP-CABLE | 3 | |
| 1809417 | 60 NUT | 3 | |
| 1279838 | 61 CONTROL GP-WASHER & WIPER | 1 | |
| 1175644 | 62 BOOT | 2 | |
| 1876065 | 63 HOSE | 1 | |
| 1175645 | 64 BOLT (M6X1X20-MM) | 3 | |
| 3E5239 | 65 RELAY AS (24-VOLT) | 1 | |
| 6C9081 | 66 LOCKWASHER | 3 |
