System And Components
257-2868 LINES GP-PILOT -CAB RISERS/N C7K1-198
Group No: 257-2868
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1345395 | 1 BRACKET AS | 2 | |
| 1345397 | 2 STRIP | 1 | |
| 1350155 | 3 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1350158 | 4 STRIP | 1 | |
| 1940158 | 5 BRACKET AS | 3 | |
| 1940159 | 6 BRACKET AS | 2 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 3 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1940166 | 7 STRIP | 3 | |
| 2238775 | 8 PLATE | 1 | |
| 2371040 | 9 GUARD | 1 | |
| 2792803 | 10 SUPPORT AS | 1 | |
| 2572983 | 11 BRACKET AS | 2 | |
| 2572984 | 12 STRIP | 2 | |
| 2572985 | 13 BRACKET AS | 2 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 3 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 2572991 | 14 HOSE AS | 1 | |
| 2572992 | 15 HOSE AS | 1 | |
| 2572993 | 16 HOSE AS | 4 | |
| 2572994 | 17 HOSE AS | 2 | |
| 2572995 | 18 HOSE AS | 2 | |
| 2572996 | 19 HOSE AS | 3 | |
| 2572997 | 20 HOSE AS | 1 | |
| 0997241 | 21 WASHER-HARD (19X34X3-MM THK) | 12 | |
| 1488336 | 22 CONNECTOR AS | 8 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488340 | 23 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488353 | 24 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488364 | 25 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488366 | 26 ELBOW AS | 12 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8987 | ELBOW | 1 | |
| 1488380 | 27 ELBOW AS | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8988 | ELBOW | 1 | |
| 1649869 | 28 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 9X2297 | CONNECTOR | 1 | |
| 4I9521 | 29 BAND-MARKER (RED, L1) | 6 | |
| 4I9522 | 30 BAND-MARKER (YELLOW, L2) | 8 | |
| 4I9523 | 31 BAND-MARKER (BLUE, L3) | 4 | |
| 4I9524 | 32 BAND-MARKER (BROWN, L4) | 2 | |
| 4I9525 | 33 BAND-MARKER (ORANGE, R1) | 6 | |
| 4I9526 | 34 BAND-MARKER (WHITE, R2) | 6 | |
| 4I9527 | 35 BAND-MARKER (GREEN, R3) | 2 | |
| 4I9528 | 36 BAND-MARKER (PURPLE, R4) | 2 | |
| 6V0683 | 37 GROMMET | 5 | |
| 6V9168 | 38 NUT (11/16-16-THD) | 12 | |
| 6V9169 | 39 NUT (13/16-16-THD) | 2 | |
| 7K1181 | 40 STRAP-CABLE | 5 | |
| 7V6571 | 41 GROMMET | 36 | |
| 7X2534 | 42 BOLT (M6X1X50-MM) | 13 | |
| 8T4121 | 43 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4136 | 44 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4137 | 45 BOLT (M10X1.5X20-MM) | 8 | |
| 8T4138 | 46 BOLT (M6X1X20-MM) | 7 | |
| 8T4139 | 47 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4223 | 48 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 9X8256 | 49 WASHER (6.6X12X2-MM THK) | 20 |
