System And Components
438-0476 SAW & TENSIONER GP-CHAINPART OF 460-9132, 460-9133 DISTRIBUTION AR, 520-4739 SAW GP-CHAIN
Group No: 438-0476
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3723855 | 1 BEARING | 1 | |
| 3723856 | 2 KIT-SEAL | 1 | |
| 2369838 | 3 BOLT-SOCKET HEAD (M6X1X8-MM) | 5 | |
| 1364184 | 4 BOLT-SOCKET HEAD (M8X1.25X40-MM) | 9 | |
| 8T0338 | 5 BOLT-SOCKET HEAD (M8X1.25X45-MM) | 2 | |
| 3723858 | 6 WASHER | 1 | |
| 2012236 | 7 BOLT | 8 | |
| 4424501 | 8 TENSIONER GP-CHAIN (AUTOMATIC) | 1 | |
| 4424505 | 9 HOUSING | 1 | |
| 4424506 | 10 PLATE-HOUSING | 1 | |
| 4424507 | 11 COVER | 1 | |
| 4424508 | 12 PLUG | 1 | |
| 2012263 | 13 FITTING-GREASE | 2 | |
| 8T0267 | 14 BOLT-SOCKET HEAD (M6X1X12-MM) | 5 | |
| 3724352 | 15 MOTOR GP-PISTON (SAW) | 1 | |
| 3724353 | 16 BOLT-SOCKET HEAD | 4 | |
| 3724354 | 17 PIN-SPRING | 2 | |
| 1990828 | 18 KEY | 1 | |
| 3724358 | 19 RING-RETAINING | 1 | |
| 3724355 | 20 SEAL-SHAFT | 1 | |
| 3724359 | 21 SPACER | 1 | |
| 3724360 | 22 SHIM | 1 | |
| 4424509 | 23 SPROCKET-DRIVE | 1 | |
| 4424510 | 24 CATCHER-CHAIN | 1 | |
| 3724364 | 25 LOCKWASHER | 1 | |
| 4424511 | 26 HOLDER GP-SAW BAR | 1 | |
| 1953836 | SETSCREW (M10X1X10-MM) | 2 | |
| 3724367 | SCREW-GUIDE | 2 | |
| 3724368 | SCREW-GUIDE | 2 | |
| 3724705 | 27 ROD-PISTON | 1 | |
| 3724706 | 28 CONNECTION | 1 | |
| 3724707 | 29 PISTON | 1 | |
| 1866540 | 30 SEAL | 1 | |
| 3724708 | 31 CAP | 1 | |
| 3724709 | 32 BOLT-SOCKET HEAD | 4 | |
| 3724710 | 33 SPACER | 1 | |
| 3724711 | 34 BARREL | 1 | |
| 3724712 | 35 RING-SEAL | 1 | |
| 3724713 | 36 SEAL-PISTON | 1 | |
| 3724714 | 37 RING-GUIDE | 1 | |
| 3E6762 | 38 SEAL-O-RING | 1 | |
| 3724715 | 39 SEAL-O-RING | 1 | |
| 3724716 | 40 SEAL-ROD | 1 | |
| 3725205 | 41 MANIFOLD | 1 | |
| 1896121 | 42 VALVE-CHECK | 1 | |
| 1893689 | 43 SEAL-O-RING | 1 | |
| 3725206 | 44 SEAL-O-RING | 1 | |
| 3725207 | 45 HOSE | 1 | |
| 3725208 | 46 FITTING | 1 | |
| 1753942 | 47 FITTING | 1 | |
| 3725209 | 48 CAP | 1 | |
| 3725210 | 49 PIPE-OIL | 1 | |
| 1833744 | 50 SEAL-O-RING | 1 | |
| 3725211 | 51 SLEEVE-PLASTIC | 1 | |
| 3725212 | 52 MANIFOLD GP-HYDRAULIC (SAW) | 1 | |
| 4424513 | 53 HOUSING | 1 | |
| 4424549 | 54 BALL BEARING | 2 | |
| 4424561 | 55 SPACER | 1 | |
| 4424567 | 56 SHAFT | 1 | |
| 4424571 | 57 SPROCKET | 1 | |
| 6V7687 | 58 LOCKNUT (M12X1.75-THD) | 1 | |
| 4424573 | 59 CAP | 1 | |
| 6V3524 | 60 FITTING-FLARED | 1 | |
| 6V0407 | 61 SEAL-BONDED | 1 | |
| 2519589 | 62 SEAL-O-RING | 1 | |
| 4424574 | 63 CLAMP | 1 | |
| 4424575 | 64 RING-RETAINING | 1 | |
| 4424577 | 65 RING-RETAINING | 1 | |
| 4424578 | 66 PLATE-CLAMP | 1 | |
| 2550696 | 67 BOLT-SOCKET HEAD (M6X1X14-MM) | 2 | |
| 4424579 | 68 SEAL | 1 | |
| 4424580 | 69 PIN | 1 | |
| 5W4881 | 70 SEAL-O-RING | 1 | |
| 4424581 | 71 CONVERTER | 1 | |
| 4424583 | 72 HARNESS-WIRING | 1 | |
| 3725237 | 73 KIT-SEAL | 1 | |
| 4460621 | 74 PLUG | 1 |
