System And Components
375-6765 DOOR GP-CABS/N FM21-UP
Group No: 375-6765
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2627954 | 1 BUMPER | 2 | |
| 2773430 | 2 PLUG-BUTTON | 3 | |
| 3786579 | 3 KIT-LATCH (LOWER) | 1 | |
| 3786580 | 4 KIT-LATCH (INNER) | 1 | |
| 3786586 | 5 HANDLE | 2 | |
| 3786587 | 6 BUSHING | 2 | |
| 3786588 | 7 KIT-LOCK | 1 | |
| 3786595 | 8 LOCK AS-DOOR | 1 | |
| 3786599 | 9 COVER | 1 | |
| 3931370 | 10 DOOR GP-CAB | 1 | |
| 3931380 | 11 KIT-LATCH | 1 | |
| 3931382 | 12 SEAL | 1 | |
| 4471835 | 13 CABLE | 1 | |
| 4471840 | 14 SEAL | 4 | |
| 4471842 | 15 COVER | 1 | |
| 4520229 | 16 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 3 | |
| 9R3494 | SPACER (8X25X2.5-MM THK) | 3 | |
| 4520264 | 17 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 3 | |
| 1053486 | 18 BOLT-SOCKET HEAD (M6X1X50-MM) | 2 | |
| 1797262 | 20 SCREW-FLAT HEAD (M8X1.25X40-MM) | 2 | |
| 1975107 | 21 SCREW-TRUSS HEAD (M6X1X60-MM) | 3 | |
| 3T0852 | 22 LOCKNUT (M8X1.25-THD) | 3 | |
| 5C8312 | 23 NUT (M4X0.7-THD) | 2 | |
| 6C4000 | 24 SHIM (1-MM THK) | 4 | |
| 7X7729 | 25 WASHER (11X25X3-MM THK) | 6 | |
| 8T0389 | 26 LOCKNUT (M10X1.5-THD) | 6 | |
| 8T4138 | 27 BOLT (M6X1X20-MM) | 2 | |
| 8T4224 | 28 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 1361613 | 29 BOLT-SOCKET HEAD (M6X1X30-MM) | 2 | |
| 9X2044 | 30 SCREW-TRUSS HEAD (M6X1X16-MM) | 6 | |
| 9X6155 | 31 BOLT-SOCKET HEAD (M6X1X16.7-MM) | 1 | |
| 9X8256 | 32 WASHER (6.6X12X2-MM THK) | 7 | |
| 2627953 | 33 WASHER (8.5X38X5-MM THK) | 1 |
