System And Components
168-9505 LINES GP-BLADES/N CKE1-UP
Group No: 168-9505
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1225373 | 1 VALVE GP-CONTROL (BLADE, WITH RELIEF)(PILOT OPERATED) | 1 | |
| 1536259 | 2 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8777 | TEE-FACE SEAL | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 2076420 | 3 TUBE AS | 1 | |
| 2076422 | 4 TUBE AS | 1 | |
| 7J9108 | 5 SEAL-O-RING | 4 | |
| 1488341 | 6 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1504048 | 7 ELBOW AS | 3 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8722 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 0931295 | 8 CLAMP | 2 | |
| 8T4194 | 9 BOLT (M12X1.75X50-MM) | 2 | |
| 8T4223 | 10 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 1391762 | 11 HOSE AS | 2 | |
| 1391765 | 12 HOSE AS | 2 | |
| 1348697 | 13 HOSE AS | 1 | |
| 8T4192 | 14 BOLT (M12X1.75X25-MM) | 3 | |
| 1536232 | 15 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T0120 | ELBOW | 1 | |
| 5P7466 | 16 CLIP (SLOT) | 1 | |
| 5P7467 | 17 CLIP (TAB) | 1 | |
| 5P8112 | 18 GROMMET | 1 | |
| 2076269 | 19 HOSE AS | 1 | |
| 1136394 | 20 HOSE AS | 1 | |
| 1875809 | 21 HOSE AS | 1 | |
| 1875812 | 22 HOSE AS | 1 | |
| 1488355 | 23 ELBOW AS | 2 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9005 | ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488342 | 24 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8632 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488315 | 25 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488322 | 26 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8640 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1624695 | 29 SWIVEL GP | 1 | |
| 1215203 | 31 BOOT | 1 | |
| 1215204 | 32 RETAINER | 1 | |
| 0990913 | 33 CLAMP-HOSE | 1 | |
| 1488447 | 34 TEE AS-SWIVEL | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 7X0872 | TEE-SWIVEL | 1 | |
| 1645567 | 35 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 6V0852 | 36 CAP-DUST | 1 | |
| 1950106 | 37 ELBOW | 2 | |
| 7M8485 | 38 SEAL-O-RING | 2 | |
| 6V9746 | 39 SEAL-O-RING | 2 | |
| 1467170 | 41 GUARD | 1 | |
| 2290968 | 42 PLATE | 1 | |
| 5A3604 | 43 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 3 |
