System And Components
165-9569 VALVE GP-PILOT -JOYSTICKS/N BEA1-UP; BDE1-UP; BBL1-UP; BCN1-UP
Group No: 165-9569
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1659431 | 1 PLATE | 1 | |
| 4I6365 | 2 JOINT | 1 | |
| 1184087 | 3 SPRING | 4 | |
| 1659444 | 4 SEAT-SPRING | 2 | |
| 0961628 | 5 PLUG | 2 | |
| 1659436 | 6 SEAT | 2 | |
| 1659460 | 7 SPRING | 2 | |
| 1659461 | 8 SPRING | 4 | |
| 1659439 | 9 BUSHING | 1 | |
| 1659448 | 10 SEAL-O-RING | 1 | |
| 1680794 | 11 PLATE | 1 | |
| 0964498 | 12 WASHER-SEALING | 2 | |
| 6V8337 | 13 BOLT-SOCKET HEAD (M8X1.25X35-MM) | 2 | |
| 1710087 | 14 BELLOWS | 1 | |
| 5B9304 | 15 SCREW-DRIVE (NO 2X3/16-IN) | 2 | |
| 7Y0468 | 16 PIN-SPRING | 1 | |
| 1772805 | 17 BODY AS | 1 | |
| 0996137 | 18 WASHER (6.1X9X0.2-MM THK) | 4 | |
| 1659442 | 19 SPRING | 2 | |
| 1659435 | 20 SEAT | 2 | |
| 0951586 | 21 SEAL-O-RING | 4 | |
| 1659443 | 22 SEAT-SPRING | 2 | |
| 1659438 | 23 PLATE | 1 | |
| 1184086 | 24 ROD | 4 | |
| 1315915 | 25 NUT-SPECIAL | 1 | |
| 0940876 | 26 SEAL | 4 | |
| 1907750 | 27 SPRING | 4 | |
| 1907751 | 28 SPRING | 4 | |
| 4I1764 | 29 PLATE | 1 |
