System And Components
176-4673 LINES GP-FRONT -SWING BOOMS/N BNE1-UP
Group No: 176-4673
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0931291 | 1 CLAMP | 2 | |
| 2M9780 | 2 SEAL-O-RING | 2 | |
| 7J9108 | 3 SEAL-O-RING | 10 | |
| 1659597 | 4 VALVE GP-CHECK (1-PUMP/2-PUMP FLOW) | 1 | |
| 1400727 | 5 VALVE GP-RELIEF (LINE) | 2 | |
| 1488340 | 6 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 0965766 | 7 CLAMP | 4 | |
| 8T6466 | 8 BOLT (M10X1.5X60-MM) | 4 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4133 | 10 NUT (M10X1.5-THD) | 4 | |
| 1087251 | 11 CONNECTOR | 1 | |
| 3K0360 | 12 SEAL-O-RING | 1 | |
| 4I6188 | 13 VALVE AS-MANUAL (1-WAY/2-WAY FLOW) | 2 | |
| 1347113 | HANDLE | 1 | |
| 1347114 | BOLT-SPECIAL | 1 | |
| 1347115 | PLATE | 1 | |
| 1950090 | PLATE | 1 | |
| 1488393 | 14 ELBOW AS | 2 | |
| 6V9852 | ELBOW (SWIVEL) | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 4 | |
| 1360207 | 16 STRAP-CABLE (BLACK) | 1 | |
| 1764694 | 17 CONNECTOR | 1 | |
| 1511843 | 18 PLATE | 2 | |
| 1764794 | 19 TUBE AS | 1 | |
| 1391828 | 20 TUBE AS | 1 | |
| 1764795 | 21 TUBE AS | 1 | |
| 1689336 | 22 TUBE AS | 1 | |
| 1689393 | 23 CONNECTOR | 1 | |
| 1689390 | 24 HOSE AS | 1 | |
| 1488342 | 25 CONNECTOR AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8632 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488446 | 26 TEE AS-SWIVEL | 1 | |
| 6V9838 | TEE-SWIVEL | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 6V8555 | 27 NUT-FACE SEAL (1-14-THD) | 1 | |
| 6V9510 | PLUG (1-14-THD) | 2 | |
| 1488416 | 28 REDUCER AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8939 | REDUCER-O-RING | 1 | |
| 1689386 | 29 HOSE AS | 1 | |
| 1876979 | 30 PIPE AS | 1 | |
| 1689332 | 31 TUBE AS | 1 | |
| 1689334 | 32 TUBE AS | 1 | |
| 1764796 | 33 HOSE AS | 1 | |
| 1764799 | 34 HOSE AS | 1 | |
| 1511793 | 35 HOSE AS | 1 |
