System And Components
198-7674 CAB GPS/N BNN1-UP; CBT1-UP
Group No: 198-7674
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E1384 | 1 BUMPER-CONICAL | 2 | |
| 1981747 | 2 LINER | 1 | |
| 4I4392 | 4 CLIP | 3 | |
| 5C7261 | 6 NUT (M8X1.25-THD) | 2 | |
| 5C9553 | 7 BOLT (M6X1X16-MM) | 6 | |
| 5P6872 | 8 MIRROR AS | 1 | |
| 6C8584 | 9 SCREW (M6X1X8-MM) | 3 | |
| 6C8972 | 10 HOOK | 1 | |
| 6C8986 | 11 CLIP-AXLE | 2 | |
| 6C9000 | 12 SUPPORT | 1 | |
| 6C9001 | 13 CLAMP | 1 | |
| 6C9078 | 14 WASHER | 10 | |
| 6C9087 | 15 WASHER | 3 | |
| 6C9121 | 16 BRACKET AS-LAMP | 1 | |
| 6C9122 | 17 LAMP (24-VOLT)(CAB) | 2 | |
| 6C9131 | 18 SCREW-TAPPING | 2 | |
| 6C9232 | 19 RIVET | 8 | |
| 6C9235 | 20 PLATE-IDENTIFICATION (CAB) | 1 | |
| 6C9236 | 21 RETAINER | 2 | |
| 6C9237 | 22 RIVET | 2 | |
| 6C9241 | 23 BOLT | 2 | |
| 1017396 | 24 BOLT-SOCKET HEAD (M10X1.5X50-MM) | 2 | |
| 8C0572 | 25 WASHER (8.8X25.5X2-MM THK) | 2 | |
| 8T4133 | 26 NUT (M10X1.5-THD) | 3 | |
| 6V7357 | 27 BOLT (M6X1X25-MM) | 4 | |
| 9N1995 | 28 RIVET-POP | 2 | |
| 9U8263 | 29 COVER | 1 | |
| 5P1075 | 30 WASHER-HARD (10.2X22.5X3-MM THK) | 6 | |
| 1198340 | 31 SEAL | 2 | |
| 1912768 | 32 COVER | 1 | |
| 1204777 | 33 COVER | 2 | |
| 1396039 | 34 NUT-RETAINER (U-TYPE) | 2 | |
| 1205737 | 35 WASHER (17.5X40X4-MM THK) | 2 | |
| 1335514 | 36 HAMMER | 1 | |
| 1516789 | 37 GLASS (RH) | 1 | |
| 1516790 | 38 GLASS (LH)(LH) | 1 | |
| 1912767 | 39 COVER | 1 | |
| 1566599 | 40 STRIKER | 1 | |
| 1613660 | 41 BRACKET AS | 1 | |
| 1613685 | 42 ROD | 1 | |
| 1613697 | 43 GUARD | 1 | |
| 1640528 | 45 LEVER GP-CAB DOOR | 1 | |
| 1566642 | LEVER AS | 1 | |
| 1640664 | BRACKET | 1 | |
| 1761941 | PIN | 1 | |
| 1858280 | WASHER-WAVE (10.5X15X0.3-MM THK) | 1 | |
| 1858281 | SPRING | 1 | |
| 1644344 | 46 PLUG | 8 | |
| 1146658 | 47 WASHER (6.5X17X1-MM THK) | 2 | |
| 1674067 | 48 GLASS (TOP) | 1 | |
| 1674070 | 49 COVER | 1 | |
| 1674079 | 50 LINER (RH) | 1 | |
| 1674080 | 51 LINER (LH) | 1 | |
| 1674081 | 52 LINER (ROOF) | 1 | |
| 1674089 | 53 COVER AS | 1 | |
| 1674099 | 54 PLATE | 1 | |
| 2110007 | 55 CAB AS | 1 | |
| 1674142 | 56 GLASS (REAR) | 1 | |
| 6C4000 | 58 SHIM (1-MM THK) | 4 | |
| 1674154 | 59 HANDRAIL AS | 1 | |
| 1674158 | 60 PLATE | 1 | |
| 1674159 | 61 PLATE | 1 | |
| 1674160 | 62 PLATE | 2 | |
| 1677042 | 66 SEAL | 2 | |
| 1677272 | 67 FILM-IDENTIFICATION (CATERPILLAR, CAB, REAR) | 1 | |
| 1717426 | 68 CABLE AS | 1 | |
| 1761939 | 69 LEVER AS | 1 | |
| 1761942 | 70 COVER | 1 | |
| 1761973 | 71 LATCH AS | 1 | |
| 8T0269 | 72 BOLT-SOCKET HEAD (M6X1X20-MM) | 2 | |
| 1674098 | 73 HANDLE | 1 | |
| 1204779 | 76 HOOK | 12 | |
| 8T4121 | 78 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4136 | 79 BOLT (M10X1.5X25-MM) | 9 | |
| 8T4200 | 80 BOLT (M8X1.25X16-MM) | 3 | |
| 9X2044 | 81 SCREW-TRUSS HEAD (M6X1X16-MM) | 29 | |
| 8T4192 | 83 BOLT (M12X1.75X25-MM) | 4 | |
| 8T4223 | 85 WASHER-HARD (13.5X25.5X3-MM THK) | 6 |
