System And Components
161-3760 CONSOLE GP-OPERATOR -RHS/N PAD1-UP
Group No: 161-3760
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y9096 | 1 SCREW-TRUSS HEAD (M6X1X6-MM) | 6 | |
| 1282135 | 2 SCREW-TRUSS HEAD (M6X1X13-MM) | 4 | |
| 1785400 | 3 SUPPORT AS | 1 | |
| 1785426 | 4 SCREW-TAPPING | 8 | |
| 1785519 | 5 COVER | 1 | |
| 1785522 | 6 COVER | 1 | |
| 1785524 | 7 ADJUSTMENT GP-CONSOLE | 1 | |
| 1785529 | 8 COVER | 1 | |
| 2844567 | 9 CASE | 1 | |
| 1785548 | 10 COVER | 1 | |
| 1785629 | 11 LATCH | 1 | |
| 1785632 | 12 BRACKET | 1 | |
| 1858163 | 13 SCREW-MACHINE (M5X0.8X8-MM) | 3 | |
| 1961565 | 14 BRACKET | 1 | |
| 2Y5687 | 15 WASHER (8.5X16X1.2-MM THK) | 6 | |
| 1195026 | 16 SCREW-PAN HEAD (10-16X0.63-IN) | 5 | |
| 1557099 | 17 NUT | 10 | |
| 9X2042 | 18 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 | |
| 2014441 | 19 SEAL (5-CM) |
