System And Components
431-8611 HATCH GP-ROOFS/N DTG1-UP
Group No: 431-8611
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1892847 | 1 SEAL | 1 | |
| 4564565 | 2 HATCH AS | 1 | |
| 1761949 | 2A BRACKET AS | 2 | |
| 4564564 | 2B HINGE AS | 2 | |
| 2482714 | 2C NUT-ACORN (M6X1-THD) | 2 | |
| 2597352 | 3 CATCH | 1 | |
| 3981505 | 4 SPRING AS-GAS (HATCH) | 2 | |
| 3B4505 | 5 LOCKWASHER | 4 | |
| 5D4822 | 6 RING-RETAINING | 4 | |
| 8T4200 | 7 BOLT (M8X1.25X16-MM) | 4 | |
| 8T4224 | 8 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X2042 | 9 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 |
