301-9249 RISER GP-HYDRAULIC ADJ CABS/N D3S1-174

Group No: 301-9249
Part NumberPart NameQty
1R62251 PIN AS8
7Y18632 SPACER (20.5X38X34-MM THK)2
09300653 SHIM (1-MM THK)8
09303494 WASHER (22X60X6-MM THK)2
09314335 SEAL-LIP TYPE16
13327176 SHIM (0.5-MM THK)8
13469557 GROMMET2
13585748 BOLT AS11
14671129 GROMMET1
302987610 BUMPER2
237112611 LINK & BEARING AS1
3B8489FITTING-GREASE (1/8-27 PTF)2
229101011A BUSHING4
237115912 PLATE1
237116013 PLATE1
237116114 WASHER (63X100X8-MM THK)4
237122415 COVER AS1
237124116 PIN AS1
237125017 GUARD4
237125118 GUARD1
237125519 MIRROR GP-DOWN VIEW (CAB RISER)1
257284420 WASHER (58X90X9-MM THK)1
257307921 PIN AS1
269297522 FRAME AS-CAB RISER1
276941923 PIN AS1
292475524 WASHER (22X144X12-MM THK)2
298524225 SPACER (17X28X12-MM THK)4
298793426 FRAME AS1
299003227 LINK & BEARING AS1
3B8489FITTING-GREASE (1/8-27 PTF)2
229101027A BUSHING4
302824928 CYLINDER & LINES GP-CAB RISER1
086029729 WASHER (13X50X6-MM THK)6
3V924430 WASHER (16.5X50X5-MM THK)4
4V528231 GROMMET2
5C726132 NUT (M8X1.25-THD)2
7X254033 BOLT (M8X1.25X120-MM)1
7X255334 BOLT (M16X2X40-MM)4
7X256435 BOLT (M20X2.5X90-MM)2
7X257636 BOLT (M24X3X70-MM)9
7Y545637 GROMMET2
8T412338 WASHER (22X35X3.5-MM THK)2
8T416739 WASHER-HARD (26X44X4-MM THK)9
8T417940 BOLT (M12X1.75X20-MM)2
8T419241 BOLT (M12X1.75X25-MM)10
8T422342 WASHER-HARD (13.5X25.5X3-MM THK)6
107167843 GUARD (47.6-CM EACH)
107167843A GUARD (18.2-CM)
318592944 GUARD1
