System And Components
307-0547 WIRING GP-ENGINES/N RNY999-UP
Group No: 307-0547
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E5239 | 1 RELAY AS (24-VOLT) | 5 | |
| 4B5324 | 2 WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 1230316 | 3 DIODE AS | 6 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 1600564 | 4 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1637451 | 5 BRACKET | 1 | |
| 1783620 | 6 STRAP-DUAL CLAMP | 3 | |
| 2299780 | 7 BUSHING | 4 | |
| 2486363 | 8 BRACKET AS | 1 | |
| 8C3334 | RIVET-TUBULAR | 2 | |
| 2905562 | 9 MOUNT (DUAL SWIVEL) | 1 | |
| 3071986 | 10 HARNESS AS-SENSOR | 1 | |
| 8T5346 | TUBE-HEAT SHRINK (19.1-MM DIA)(12-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 9X1813 | SLEEVE (30-CM) | ||
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 1762943 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 3078414 | 11 BRACKET | 1 | |
| 1330970 | 12 RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 1743016 | 13 PLUG AS-RESISTOR (3-PIN, 120 OHM) | 1 | |
| 2059920 | 14 STRAP-CABLE | 1 | |
| 2771873 | 15 CLIP (LADDER) | 3 | |
| 3523964 | 16 CLIP (LADDER) | 2 | |
| 3523968 | 17 CLIP (LADDER) | 1 | |
| 3684451 | 18 HARNESS AS-ENGINE | 1 | |
| 4P7581 | 19 CLIP (LADDER) | 13 | |
| 4P8134 | 20 CLIP (LADDER) | 6 | |
| 5M3062 | 21 BOLT (3/8-16X0.75-IN) | 1 | |
| 5P1075 | 22 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 5P4115 | 23 WASHER-HARD (7.2X19X2-MM THK) | 8 | |
| 6V8185 | 24 NUT (1/4-20-THD) | 4 | |
| 6V8801 | 25 NUT (3/8-16-THD) | 3 | |
| 7K1181 | 26 STRAP-CABLE | 48 | |
| 7X2501 | 27 BOLT (1/4-20X1.25-IN) | 4 | |
| 8T2501 | 28 BOLT (3/8-16X2-IN) | 2 | |
| 8T2502 | 29 BOLT (3/8-16X1.125-IN) | 1 | |
| 8T4896 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 8T9371 | 31 BOLT (3/8-16X0.5-IN) | 1 | |
| 9X6258 | 32 SCREW-MACHINE (6-32X0.5-IN) | 4 | |
| 3523970 | 33 CLIP (LADDER) | 1 | |
| 3523966 | 34 CLIP (LADDER) | 5 | |
| 5S7382 | 35 BOLT (3/8-16X1.375-IN) | 1 |
