377-0269 WIRING GP-ENGINEFOR USE WITH RIGHT HAND SERVICE ENGINE MOUNTED INSTRUMENT PANEL
Group No: 377-0269
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4B5324 | 1 WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 1600564 | 2 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1783620 | 3 STRAP-DUAL CLAMP | 3 | |
| 2486363 | 4 BRACKET AS | 1 | |
| 7C2644 | CLIP | 1 | |
| 8C3334 | RIVET-TUBULAR | 2 | |
| 2905562 | 5 MOUNT (DUAL SWIVEL) | 1 | |
| 3071986 | 6 HARNESS AS-SENSOR | 1 | |
| 8T5346 | TUBE-HEAT SHRINK (19.1-MM DIA)(12-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 9X1813 | SLEEVE (30-CM) | ||
| 1762943 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 3684450 | 7 HARNESS AS-ENGINE | 1 | |
| 2697678 | 8 CLIP | 1 | |
| 2059920 | 9 STRAP-CABLE | 1 | |
| 2771873 | 10 CLIP (LADDER) | 2 | |
| 3523964 | 11 CLIP (LADDER) | 5 | |
| 3523966 | 12 CLIP (LADDER) | 5 | |
| 3523968 | 13 CLIP (LADDER) | 1 | |
| 4P7581 | 14 CLIP (LADDER) | 4 | |
| 4P8134 | 15 CLIP (LADDER) | 6 | |
| 6V8801 | 16 NUT (3/8-16-THD) | 3 | |
| 7K1181 | 17 STRAP-CABLE | 37 | |
| 8T2501 | 18 BOLT (3/8-16X2-IN) | 2 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 8T9371 | 20 BOLT (3/8-16X0.5-IN) | 2 | |
| 9B7237 | 21 BOLT (3/8-16X1.25-IN) | 2 | |
| 9X6258 | 22 SCREW-MACHINE (6-32X0.5-IN) | 4 | |
| 3523970 | 23 CLIP (LADDER) | 1 |
