System And Components
291-7458 WIRING GP-CABS/N GTN1-UP
Group No: 291-7458
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 4 | |
| 7I2673 | 2 STRAP-CABLE | 3 | |
| 7K1181 | 3 STRAP-CABLE | 5 | |
| 9G7641 | 4 SWITCH GP-START (ENGINE, KEY) | 1 | |
| 1028016 | 5 RESISTOR AS (BACKUP) | 1 | |
| 1321829 | 6 ALARM GP (24-VOLT) | 1 | |
| 1636795 | 7 STRAP-CABLE | 20 | |
| 1673593 | 8 STRAP | 1 | |
| 2277575 | 9 PANEL-CONTROL (SWITCH) | 1 | |
| 2677931 | 10 BRACKET AS | 1 | |
| 2677935 | 11 STRIP AS | 1 | |
| 3068782 | 12 HARNESS AS-CAB | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 4 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 15 | |
| 3S2093 | STRAP-CABLE | 25 | |
| 7Y3951 | TERMINAL-BLADE (14-GA) | 2 | |
| 7Y3952 | PLUG-CONNECTOR (2-PIN) | 2 | |
| 7Y3962 | TERMINAL-BULLET (MALE) | 2 | |
| 7Y3964 | TUBE | 2 | |
| 7Y3963 | TERMINAL-BULLET (FEMALE) | 6 | |
| 7Y3965 | TUBE | 6 | |
| 7Y3993 | TERMINAL-BLADE (12-GA) | 2 | |
| 8C6354 | CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 8T8737 | PLUG-SEAL | 72 | |
| 9W1951 | RECEPTACLE AS-CONNECTOR (9-PIN) | 1 | |
| 1027965 | TERMINAL (14-GA TO 20-GA) | 16 | |
| 1069615 | PIN-CONNECTOR | 2 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 7 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(13-CM) | ||
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(70-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(30-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 139 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 139 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 6 | |
| 1274005 | GROMMET | 2 | |
| 2L8066 | TERMINAL-RING (10-GA TO 12-GA, NO. 10 SCREW) | 1 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 4 | |
| 2L8069 | TERMINAL-RING (2-GA TO 10-GA, 3/8-IN SCREW) | 1 | |
| 1769299 | KIT-RECEPTACLE (3-PIN) | 4 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 47 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 47 | |
| 1532602 | RECEPTACLE-CONNECTOR (1-PIN) | 2 | |
| 1532620 | PLUG AS-CONNECTOR (54-PIN, BLACK) | 1 | |
| 1636759 | SEAL | 1 | |
| 1532630 | PLUG AS-CONNECTOR (54-PIN, BROWN) | 1 | |
| 1636759 | SEAL | 1 | |
| 1532631 | TERMINAL (14-GA TO 20-GA) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 3 | |
| 1636659 | CONNECTOR-PLUG (12-PIN) | 1 | |
| 1636699 | CONNECTOR-PLUG (18-PIN) | 1 | |
| 1636790 | TERMINAL (FEMALE) | 19 | |
| 1636803 | PLUG-CONNECTOR (5-PIN) | 4 | |
| 1673487 | WEDGE-PLUG LOCK (5-PIN) | 4 | |
| 1743016 | PLUG AS-RESISTOR (3-PIN, 120 OHM) | 4 | |
| 1974385 | DIODE | 2 | |
| 2304009 | PLUG AS-CONNECTOR (12-PIN) | 7 | |
| 2647034 | SEAL-CONNECTOR | 1 | |
| 2397356 | PLUG AS-CONNECTOR (12-PIN) | 2 | |
| 2647034 | SEAL-CONNECTOR | 1 | |
| 2434510 | RECEPTACLE AS-CONNECTOR (12-PIN) | 4 | |
| 0969278 | 13 SCREW-PAN HEAD | 3 | |
| 7X2619 | 14 BOLT (M6X1X10-MM) | 2 | |
| 8T0328 | 15 WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4133 | 17 NUT (M10X1.5-THD) | 1 | |
| 8T6693 | 18 SCREW-MACHINE (M5X0.8X16-MM) | 1 | |
| 9X2042 | 19 SCREW-TRUSS HEAD (M6X1X12-MM) | 6 | |
| 9X8256 | 20 WASHER (6.6X12X2-MM THK) | 2 |
