System And Components
388-9642 PUMP GP-PISTON -IMPLEMENTS/N 2T91-UP
Group No: 388-9642
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3760900 | 1 ROTATING GP-PUMP | 1 | |
| 1749994 | 2 PISTON-CONTROL | 1 | |
| 2747452 | 3 LINK-CONTROL | 1 | |
| 1392840 | 4 SEAL-SHAFT | 1 | |
| 3469615 | 5 VALVE GP-PUMP CONTROL (IMPLEMENT PUMP) | 1 | |
| 1687317 | 6 SWASHPLATE | 1 | |
| 1972850 | 7 SHAFT | 4 | |
| 3107267 | 8 PLUG-CONTROL | 1 | |
| 1682197 | 9 SPRING | 1 | |
| 1682203 | 10 SHIM-SHAFT (3-MM THK) | 2 | |
| 1906507 | 11 RING-STOP | 1 | |
| 3P1210 | 12 CONE-BEARING | 1 | |
| 8J0412 | 13 CUP-BEARING | 1 | |
| 9W2109 | 14 CONE-BEARING | 1 | |
| 9W2110 | 15 CUP-TAPERED ROLLER | 1 | |
| 2820919 | 16 BEARING-CRADLE | 1 | |
| 2820918 | 17 BEARING-CRADLE | 1 | |
| 8T2503 | 18 BOLT-SOCKET HEAD (M14X2X35-MM) | 4 | |
| 1927470 | 19 SEAL-O-RING | 1 | |
| 9X8979 | 20 DOWEL | 1 | |
| 9S8006 | 21 PLUG (7/8-14-THD) | 1 | |
| 2M9780 | 22 SEAL-O-RING | 1 | |
| 6R7943 | 23 SCREW (M5X0.8X15-MM) | 2 | |
| 3760898 | 24 PLATE-VALVE | 1 | |
| 2807870 | 25 GASKET | 1 | |
| 9S8002 | 26 PLUG (7/16-20-THD) | 1 | |
| 3J7354 | 27 SEAL-O-RING | 1 | |
| 8T8442 | 28 BOLT-SOCKET HEAD (M6X1X30-MM) | 4 | |
| 1683504 | 29 SEAL | 2 | |
| 1204394 | 30 PLUG-BREAK OFF | 2 | |
| 1806213 | 31 RING-RETAINING | 1 |
