System And Components
272-7051 CONSOLE GP-OPERATORS/N MAN244-341
Group No: 272-7051
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3483321 | 1 PANEL GP-INSTRUMENT | 1 | |
| 2812515 | 2 HARNESS AS-CONSOLE | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 56 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 56 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 2 | |
| 1552256 | KIT-CONNECTING PLUG (12-PIN) | 2 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 2 | |
| 1907614 | KIT-RECEPTACLE (12-PIN) | 2 | |
| 1945226 | TERMINAL AS (16-GA) | 56 | |
| 1945227 | TERMINAL AS (14-GA) | 56 | |
| 1107887 | 3 SWITCH AS-START (KEY) | 1 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 1787539 | 4 RECEPTACLE AS (POWER SUPPLY) | 1 | |
| 2848905 | 5 CONTROL GP-UNPRGMED MONITOR (ADVISOR) | 1 | |
| 3045687 | 6 CONTROL GP-UNPROGRAMMED (MACHINE) | 1 | |
| 7K1181 | 7 STRAP-CABLE | 10 | |
| 4P7429 | 8 CLIP (LADDER) | 1 | |
| 2823067 | 9 PLATE | 4 | |
| 1305300 | 10 CLIP | 10 | |
| 8T4205 | 11 WASHER-HARD (7.2X14.5X2-MM THK) | 19 | |
| 8T4171 | 12 BOLT (M6X1X12-MM) | 4 | |
| 1286157 | 13 PLATE | 1 | |
| 1414976 | 14 SCREW-WASHER HEAD (4-40X0.5-IN) | 4 | |
| 8T9655 | 15 MOUNT-ISOLATION | 8 | |
| 8T9658 | 16 SPACER (8.2X12.7X25.4-MM THK) | 4 | |
| 5P4116 | 17 WASHER-HARD (8.8X20.5X2-MM THK) | 7 | |
| 5C7261 | 18 NUT (M8X1.25-THD) | 13 | |
| 8C6354 | 19 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 1G9090 | 20 S-HOOK | 1 | |
| 3E6328 | 21 ALARM GP (24-VOLT) | 1 | |
| 2823098 | 22 CLAMP | 2 | |
| 2796446 | 23 CLIP | 1 | |
| 5A3604 | 24 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 4 | |
| 8T4224 | 25 WASHER-HARD (8.8X16X2-MM THK) | 11 | |
| 8T4200 | 26 BOLT (M8X1.25X16-MM) | 3 | |
| 4P8134 | 27 CLIP (LADDER) | 1 | |
| 1G9089 | 28 CHAIN (1-DM) | ||
| 9X1046 | 29 SCREW (M4X0.7X18-MM) | 10 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4244 | 31 NUT (M12X1.75-THD) | 1 | |
| 2980636 | 32 ANGLE | 1 | |
| 5C2890 | 33 NUT (M6X1-THD) | 6 | |
| 8T4138 | 34 BOLT (M6X1X20-MM) | 6 | |
| 2502297 | 35 METER GP-SERVICE (WHITE BACKLIGHT) | 1 | |
| 3080503 | 36 SPACER | 1 | |
| 8T0338 | 37 BOLT-SOCKET HEAD (M8X1.25X45-MM) | 2 | |
| 3105922 | 38 PLATE | 1 | |
| 1272170 | 39 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 4 | |
| 1080358 | 40 FLASHER AS (24-VOLT)(TURN SIGNAL) | 1 | |
| 6V3507 | 41 SEAL-RECTANGULAR | 1 | |
| 3520244 | 42 WASHER-HARD (8.8X20.5X2-MM THK) | 4 |
