System And Components
247-3134 STEERING COLUMN GPS/N MAN1-341
Group No: 247-3134
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7R5382 | 1 SPRING | 1 | |
| 6V3812 | 2 BEARING AS-BALL | 2 | |
| 8R2916 | 3 COVER AS (CAT STEERING WHEEL) | 1 | |
| 9M4388 | 4 DOWEL | 1 | |
| 0006321 | 5 NUT (13/16-20-THD) | 1 | |
| 0817511 | 6 RING | 3 | |
| 1459291 | 7 STEERING WHEEL AS | 1 | |
| 1537368 | 8 PLUG | 1 | |
| 1958090 | 9 SENSOR GP-POSITION (STEERING) | 1 | |
| 2472988 | 10 STEERING AS | 1 | |
| 2473519 | 11 TUBE | 3 | |
| 2473589 | 12 ARM AS | 1 | |
| 2473763 | 13 ARM | 1 | |
| 2503949 | 14 SPACER | 1 | |
| 2838323 | 15 CONTROL AS-STEERING (FORCE CONTROL) | 1 | |
| 2920965 | 16 SHAFT-STEERING | 1 | |
| 3033002 | 17 PLATE | 1 | |
| 2K8467 | 18 PIN-SPRING | 1 | |
| 3E4333 | 19 KEY-WOODRUFF | 1 | |
| 4B4274 | 20 WASHER (5.5X13X1.2-MM THK) | 2 | |
| 5C7261 | 21 NUT (M8X1.25-THD) | 3 | |
| 6V0894 | 22 SEAL-O-RING | 1 | |
| 7X2537 | 23 BOLT (M8X1.25X35-MM) | 1 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4224 | 25 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T5005 | 26 BOLT (M10X1.5X70-MM) | 3 | |
| 8T7368 | 27 SCREW-MACHINE (10-32X28.58-MM) | 2 |
