System And Components
307-9156 BOX GP-RELAYPART OF 307-9155 WIRING GP-HEATER
Group No: 307-9156
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1160118 | 1 CLIP | 1 | |
| 2555011 | 2 RELAY AS (24-VOLT)(HEATER) | 6 | |
| 3079157 | 3 HARNESS AS-BOX (HEATER RELAY) | 1 | |
| 7T0093 | PIN-CONNECTOR (12-GA TO 14-GA) | 12 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 7 | |
| 9G3695 | PLUG-SEAL | 5 | |
| 1038133 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1779653 | KIT-RECEPTACLE (4-PIN) | 3 | |
| 2972480 | SPACER | 2 | |
| 3002101 | TERMINAL | 32 | |
| 3013291 | TERMINAL | 5 | |
| 2L8078 | TERMINAL-RING (14-GA TO 16-GA, 5/16-IN SCREW) | 5 | |
| 5P1478 | TERMINAL-FORK (10-GA TO 12-GA, NO. 10 SCREW) | 24 | |
| 3125029 | 4 BOX AS-RELAY | 1 | |
| 3125031 | 5 COVER | 1 | |
| 1313540 | 7 LOCKNUT (M8X1.25-THD) | 1 | |
| 1388454 | 8 SCREW-TRUSS HEAD (M4X0.7X10-MM) | 12 | |
| 5C2890 | 9 NUT (M6X1-THD) | 4 | |
| 5P7970 | 10 NUT (M8X1.25-THD) | 1 | |
| 6R7653 | 11 SCREW (M6X1X15-MM) | 4 | |
| 7X2536 | 12 BOLT (M8X1.25X14-MM) | 2 | |
| 8T0328 | 13 WASHER-HARD (5.5X10X1-MM THK) | 12 | |
| 8T4171 | 14 BOLT (M6X1X12-MM) | 2 | |
| 8T4224 | 15 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9M1974 | 16 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9X8256 | 17 WASHER (6.6X12X2-MM THK) | 4 | |
| 8T6912 | 18 BOLT (M8X1.25X50-MM) | 1 | |
| 1305300 | 19 CLIP | 2 |
