System And Components
356-4233 BOX GP-RELAY35-KW
Group No: 356-4233
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2972480 | 1 SPACER | 2 | |
| 3002101 | 2 TERMINAL | 24 | |
| 3013291 | 3 TERMINAL | 4 | |
| 3125031 | 4 COVER | 1 | |
| 3482408 | 5 RELAY AS (24-VOLT)(HEATER) | 6 | |
| 3530443 | 6 HARNESS AS-BOX (HEATER, LH) | 1 | |
| 3531561 | 7 BOX AS-RELAY | 1 | |
| 3550591 | 8 HARNESS AS-BOX (HEATER CONTROL) | 1 | |
| 3550658 | 9 HARNESS AS-BOX (HEATER, RH) | 1 | |
| 3564697 | 10 HARNESS AS-BOX | 1 | |
| 1305300 | 11 CLIP | 3 | |
| 1501293 | 12 SCREW-BUTTON HEAD (M4X0.7X12-MM) | 12 | |
| 5C2890 | 13 NUT (M6X1-THD) | 4 | |
| 6R7653 | 14 SCREW (M6X1X15-MM) | 4 | |
| 7X2536 | 15 BOLT (M8X1.25X14-MM) | 2 | |
| 8T0328 | 16 WASHER-HARD (5.5X10X1-MM THK) | 12 | |
| 8T4171 | 17 BOLT (M6X1X12-MM) | 2 | |
| 8T4200 | 18 BOLT (M8X1.25X16-MM) | 1 | |
| 8T4224 | 19 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9X8256 | 20 WASHER (6.6X12X2-MM THK) | 4 | |
| 1735412 | 21 RAIL (8-CM EACH) |
