System And Components
445-0162 BOX GP-RELAYPART OF 445-0157 WIRING GP-SCREED HEATER
Group No: 445-0162
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7H3937 | 1 LOCKWASHER (EXTERNAL TOOTH) | 4 | |
| 2330059 | 2 FILM-WARNING (GROUND) | 1 | |
| 3531561 | 3 BOX AS-RELAY | 1 | |
| 3550591 | 4 HARNESS AS-BOX (HEATER CONTROL) | 1 | |
| 3913018 | 5 RELAY AS (24-VOLT) | 6 | |
| 3914790 | 6 WIRE AS (12-GA) | 2 | |
| 3925041 | 7 COVER AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 1501293 | 8 SCREW-BUTTON HEAD (M4X0.7X12-MM) | 12 | |
| 5C7261 | 9 NUT (M8X1.25-THD) | 4 | |
| 7X2536 | 10 BOLT (M8X1.25X14-MM) | 2 | |
| 8F7242 | 11 WASHER (8.7X15.9X1.6-MM THK) | 8 | |
| 8T0328 | 12 WASHER-HARD (5.5X10X1-MM THK) | 12 | |
| 8T4171 | 13 BOLT (M6X1X12-MM) | 2 |
