System And Components
286-3632 WIRING GP-HEATER -LPG HEATPART OF 286-3622 HEATER AR-SCREED
Group No: 286-3632
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1160118 | 1 CLIP | 6 | |
| 1384572 | 2 COVER | 3 | |
| 1480342 | 3 CLAMP | 6 | |
| 2080075 | 4 CLAMP-HALF | 6 | |
| 2741163 | 5 SPARK PLUG | 8 | |
| 3391645 | 6 SOLENOID-VALVE (LPG) | 4 | |
| 2793661 | 7 CABLE AS-EXTENSION (LH) | 1 | |
| 2793662 | 8 CABLE AS-EXTENSION (RH) | 1 | |
| 3079160 | 10 CONTROL & MTG GP-MACHINE | 1 | |
| 3079161 | 11 CABLE AS | 1 | |
| 3391651 | 12 WIRING GP-HEATER (LPG HEAT) | 1 | |
| 1325789 | 13 CLIP | 4 | |
| 2462207 | 14 BOLT (M6X1X40-MM) | 8 | |
| 5C7261 | 15 NUT (M8X1.25-THD) | 2 | |
| 5P7970 | 16 NUT (M8X1.25-THD) | 2 | |
| 6V8653 | 17 BOLT-SOCKET HEAD (M6X1X40-MM) | 6 | |
| 7K1181 | 18 STRAP-CABLE | 13 | |
| 8T4189 | 19 BOLT (M8X1.25X20-MM) | 9 | |
| 8T4224 | 20 WASHER-HARD (8.8X16X2-MM THK) | 13 | |
| 8T6912 | 21 BOLT (M8X1.25X50-MM) | 3 | |
| 9X8256 | 22 WASHER (6.6X12X2-MM THK) | 11 | |
| 6V4369 | 23 CLIP | 3 | |
| 2946007 | 24 BOLT-HEAD LOCKING (M6X1X18-MM) | 3 |
