System And Components
307-9155 WIRING GP-HEATERPART OF 320-2490 HEATER AR-SCREED
Group No: 307-9155
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1160118 | 1 CLIP | 30 | |
| 1384572 | 2 COVER | 3 | |
| 1480342 | 3 CLAMP | 6 | |
| 2913876 | 4 PANEL GP-CONTROL | 1 | |
| 2293128 | PANEL AS | 1 | |
| 2863636 | 5 SUPPORT | 1 | |
| 2889429 | 6 SUPPORT AS-CONTROL | 1 | |
| 7T1099 | LINK | 4 | |
| 2967912 | 7 BOX AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 2967913 | PLATE | 1 | |
| 2967914 | 8 COVER | 1 | |
| 3079146 | 9 HARNESS AS-SCREED (ELECTRIC HEAT, MAIN, RH) | 1 | |
| 3079147 | 10 HARNESS AS-SCREED (ELECTRIC HEAT, MAIN, LH) | 1 | |
| 3079156 | 11 BOX GP-RELAY | 1 | |
| 3197146 | 12 HARNESS AS-SCREED (MOUNTING) | 1 | |
| 3197147 | 13 MOUNTING GP | 1 | |
| 8T9534 | BOLT (M6X1X50-MM) | 2 | |
| 2193299 | CLAMP-HALF | 2 | |
| 3197149 | 14 HARNESS AS-SCREED (EXTENDER, RH) | 1 | |
| 3197150 | 15 HARNESS AS-SCREED (EXTENDER, LH) | 1 | |
| 1305300 | 16 CLIP | 3 | |
| 1313540 | 17 LOCKNUT (M8X1.25-THD) | 2 | |
| 1390428 | 18 CLAMP | 6 | |
| 8T4200 | 19 BOLT (M8X1.25X16-MM) | 2 | |
| 5P4116 | 20 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 5P7854 | 21 CLIP | 2 | |
| 6V4298 | 22 BOLT (M5X0.8X16-MM) | 4 | |
| 6V8653 | 23 BOLT-SOCKET HEAD (M6X1X40-MM) | 6 | |
| 7K1181 | 24 STRAP-CABLE | 6 | |
| 8T4121 | 25 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4137 | 26 BOLT (M10X1.5X20-MM) | 5 | |
| 8T4171 | 27 BOLT (M6X1X12-MM) | 4 | |
| 8T4189 | 28 BOLT (M8X1.25X20-MM) | 6 | |
| 8T4199 | 29 BOLT (M8X1.25X12-MM) | 21 | |
| 8T4224 | 30 WASHER-HARD (8.8X16X2-MM THK) | 21 | |
| 8T4970 | 31 BOLT (M6X1X14-MM) | 2 | |
| 8T6912 | 32 BOLT (M8X1.25X50-MM) | 3 | |
| 9M1974 | 33 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X8256 | 34 WASHER (6.6X12X2-MM THK) | 10 |
