System And Components
364-6477 WIRING GP-SCREEDS/N DLB450-UP
Group No: 364-6477
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I1418 | 1 SPACER (8.2X12.7X28.7-MM THK) | 4 | |
| 7K1181 | 2 STRAP-CABLE | 30 | |
| 8T9655 | 3 MOUNT-ISOLATION | 8 | |
| 1160118 | 4 CLIP | 2 | |
| 1631201 | 5 HORN AS (24-VOLT, LOW TONE) | 1 | |
| 2033977 | 6 LEVER | 2 | |
| 3446323 | 7 SPACER (13.5X30X11-MM THK) | 4 | |
| 2889418 | 8 SUPPORT | 2 | |
| 2913697 | 9 WIRING GP-SCREED (LH) | 1 | |
| 2913698 | 10 LAMP GP-SIGNAL | 1 | |
| 2935341 | 11 WIRING GP-SCREED (RH) | 1 | |
| 2935354 | 12 LIGHTING GP-ROADING | 1 | |
| 2959765 | 13 HARNESS AS-SCREED (PAVER TO SCREED) | 1 | |
| 2319895 | CONDUIT-FLEXIBLE (21.9-MM ID)(133-CM) | ||
| 9X7144 | PLUG AS-CONNECTOR (24-PIN) | 2 | |
| 3E8558 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 9X3265 | SEAL-CONNECTOR (24-PIN) | 2 | |
| 9G3695 | PLUG-SEAL | 4 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 44 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 44 | |
| 2971331 | 14 SUPPORT | 1 | |
| 2997218 | 15 SUPPORT AS | 1 | |
| 1788508 | PLATE AS | 1 | |
| 1788510 | PLATE-WELD | 1 | |
| 3045687 | 16 CONTROL GP-UNPROGRAMMED | 1 | |
| 3148922 | 17 RESISTOR AS-CONNECTION | 1 | |
| 3646474 | 18 MOUNT AS | 2 | |
| 3646485 | 19 HARNESS AS-SCREED (RH) | 1 | |
| 3646487 | 20 HARNESS AS-SCREED (LH) | 1 | |
| 3646488 | 21 HARNESS AS-CHASSIS | 1 | |
| 3671953 | 22 BRACKET | 2 | |
| 3832076 | 23 BOX GP-SCREED CONTROL (RH) | 1 | |
| 3832077 | 24 BOX GP-SCREED CONTROL (LH) | 1 | |
| 3832078 | 25 BOX GP-SCREED CONTROL | 1 | |
| 3855389 | 26 BRACKET AS | 2 | |
| 0993649 | 27 BOLT (M8X1.25X40-MM) | 4 | |
| 1305300 | 28 CLIP | 8 | |
| 1313540 | 29 LOCKNUT (M8X1.25-THD) | 4 | |
| 1325789 | 30 CLIP | 3 | |
| 1390428 | 31 CLAMP | 10 | |
| 1984777 | 32 WASHER-HARD (11X25X10-MM THK) | 4 | |
| 1R5396 | 33 BOLT (M6X1X35-MM) | 10 | |
| 5P4116 | 34 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 6V3964 | 35 WASHER-HARD (8.8X25.5X5-MM THK) | 4 | |
| 7X2537 | 36 BOLT (M8X1.25X35-MM) | 1 | |
| 7X7729 | 37 WASHER (11X25X3-MM THK) | 6 | |
| 8T0389 | 38 LOCKNUT (M10X1.5-THD) | 6 | |
| 8T4121 | 39 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 40 NUT (M10X1.5-THD) | 1 | |
| 8T4137 | 41 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4179 | 42 BOLT (M12X1.75X20-MM) | 2 | |
| 8T4189 | 43 BOLT (M8X1.25X20-MM) | 15 | |
| 8T4196 | 44 BOLT (M10X1.5X35-MM) | 6 | |
| 8T4224 | 45 WASHER-HARD (8.8X16X2-MM THK) | 20 | |
| 8T4908 | 46 BOLT (M8X1.25X25-MM) | 2 | |
| 8T6912 | 47 BOLT (M8X1.25X50-MM) | 4 | |
| 8T7547 | 48 BOLT (M8X1.25X30-MM) | 4 | |
| 9M1974 | 49 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 2961288 | 50 ELECTRONICS GP-IMPLEMENT | 1 | |
| 3913128 | 51 ELECTRONICS GP-MONITOR | 1 |
