System And Components
352-0657 BOX GP-CONTROL -RHS/N TFM1-UP
Group No: 352-0657
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3D9718 | 1 SWITCH AS-PUSH BUTTON (HORN) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 6V8832 | NUT (5/8-32-THD) | 1 | |
| 9B7233 | LOCKWASHER | 2 | |
| 3S2093 | 3 STRAP-CABLE | 7 | |
| 1165270 | 4 LAMP (24-VOLT)(EMERGENCY STOP) | 1 | |
| 7R3029 | 5 CAP-DUST | 1 | |
| 8D9537 | 6 CAP-DUST | 1 | |
| 1165275 | 7 SWITCH GP-PUSH BUTTON (OPERATOR)(EMERGENCY STOP) | 1 | |
| 1165277 | 8 BLOCK (CONTACT) | 2 | |
| 1166565 | 9 BLOCK AS (LIGHT) | 1 | |
| 8L9801 | LAMP (12-VOLT) | 1 | |
| 1554098 | 10 SCREW-BUTTON HEAD (M3X0.5X1-MM) | 10 | |
| 2468912 | 11 SWITCH GP-TOGGLE (EXTENDER WIDTH, RH) | 1 | |
| 2502299 | 12 LAMP AS-LED (24-VOLT, GREEN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 2659984 | 13 BRACKET | 1 | |
| 3783321 | 14 POTENTIOMETER AS (AUGER CONTROL) | 1 | |
| 3165717 | 15 KNOB AS (POTENTIOMETER) | 1 | |
| 3478607 | 16 KNOB (PARKING BRAKE) | 1 | |
| 3520670 | 17 HARNESS AS-BOX | 1 | |
| 3550543 | 18 FILM-IDENTIFICATION (PANEL) | 1 | |
| 3550545 | 19 PLATE | 1 | |
| 3605622 | 20 BOX GP-CONTROL (RH) | 1 | |
| 0966166 | 21 WASHER-HARD (4.5X9X1-MM THK) | 4 | |
| 1622165 | 22 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 4 | |
| 3C6969 | 23 NUT (M3X0.5-THD) | 10 | |
| 3D9872 | 24 PLUG-BUTTON | 1 | |
| 1028802 | 25 KIT-RECEPTACLE (2-PIN) | 1 | |
| 9B1117 | 26 LOCKWASHER | 20 | |
| 9G0011 | 27 SWITCH AS-TOGGLE (CONVEYOR CONTROL) | 2 | |
| 9G0011 | 27A SWITCH AS-TOGGLE (TOW POINT CONTROL, LH) | 1 | |
| 9G0011 | 27B SWITCH AS-TOGGLE (AUGER CONTROL) | 1 | |
| 9G0011 | 27C SWITCH AS-TOGGLE (TOW POINT CONTROL, RH) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 3 | |
| 9X2042 | 28 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 1075014 | 29 KNOB (CONTROL BOX) | 1 | |
| 9X8256 | 30 WASHER (6.6X12X2-MM THK) | 1 | |
| 5C2890 | 31 NUT (M6X1-THD) | 1 |
