Assembly
100%

350-7917 HEATER GP-GATES/N TFM1-UP

Group No: 350-7917
Part NumberPart NameQty
3S20931 STRAP-CABLE4
35095512 HEATER AS2
1297164RECEPTACLE AS-CONNECTOR (1-PIN)2
35802733 HARNESS AS-HEATER2
7T0093PIN-CONNECTOR (12-GA TO 14-GA)2
1297163PLUG AS-CONNECTOR (1-PIN)2
1779645KIT-RECEPTACLE (2-PIN)1
8N1541SOCKET-CONNECTOR (12-GA TO 14-GA)2
2L8069TERMINAL-RING (2-GA TO 10-GA, 3/8-IN SCREW)2
36969014 PLATE-COVER (RH)1
36969025 PLATE-COVER (LH)1
38250676 BRACKET4
7X77297 WASHER (11X25X3-MM THK)6
8T41218 WASHER-HARD (11X21X2.5-MM THK)4
8T41339 NUT (M10X1.5-THD)12
8T413610 BOLT (M10X1.5X25-MM)6
8T418611 BOLT (M10X1.5X40-MM)8
8T419112 BOLT (M10X1.5X16-MM)2
4D132613 LOCKWASHER2
7P169514 WASHER (10.5X19X3-MM THK)2
