System And Components
348-3338 PANEL GP-CIRCUIT BREAKERS/N TFM1-UP
Group No: 348-3338
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E6477 | 1 RELAY AS (24-VOLT) | 8 | |
| 8T5570 | 2 SOCKET | 1 | |
| 1054684 | 3 RELAY AS (24-VOLT) | 1 | |
| 1729200 | 4 SUPPRESSOR-ARC | 1 | |
| 2267300 | 5 CIRCUIT BREAKER AS (25-AMPERE) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 2360872 | 6 STRAP AS | 14 | |
| 8T5346 | TUBE-HEAT SHRINK (19.1-MM DIA)(2-CM) | ||
| 2806834 | 7 WIRE AS (6-GA) | 1 | |
| 2927943 | 8 PANEL AS-CIRCUIT BREAKER | 1 | |
| 3483322 | 9 HARNESS AS-CONTROL | 1 | |
| 7X6222 | PLUG AS-CONNECTOR (24-PIN) | 1 | |
| 3E8558 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 9X3265 | SEAL-CONNECTOR (24-PIN) | 2 | |
| 1471445 | PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 1471446 | PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 1599322 | SEAL-O-RING | 1 | |
| 1835784 | PLUG AS-CONNECTOR (40-PIN) | 3 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 9X3490 | SEAL-CONNECTOR (40-PIN) | 2 | |
| 8T8737 | PLUG-SEAL | 124 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 2 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1907614 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 2 | |
| 7T6365 | HOUSING-RECEPTACLE | 8 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 25 | |
| 8N1544 | PIN-CONNECTOR (8-GA) | 1 | |
| 8N1546 | PIN-CONNECTOR (6-GA) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 8 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 1552256 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 3 | |
| 1275484 | RECEPTACLE AS-CONNECTOR (1-PIN) | 1 | |
| 1275486 | RECEPTACLE AS-CONNECTOR (1-PIN) | 1 | |
| 1602244 | SLEEVE-ABRASION (15-IN) | ||
| 1602246 | SLEEVE-ABRASION (38-IN) | ||
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 5P4571 | TERMINAL-BLADE (14-GA TO 16-GA) | 2 | |
| 1311489 | TERMINAL AS-RING (6-GA TO 8-GA) | 2 | |
| 6H3592 | TERMINAL-RING (6-GA TO 8-GA, 5/16-IN SCREW) | 1 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(4-CM) | ||
| 1311492 | TERMINAL AS-RING (6-GA TO 8-GA) | 4 | |
| 3K4528 | TERMINAL-RING (6-GA TO 8-GA, 1/2-IN SCREW) | 1 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(4-CM) | ||
| 2L8065 | TERMINAL-RING (10-GA TO 12-GA, NO. 8 SCREW) | 14 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 5 | |
| 2L8076 | TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW) | 2 | |
| 7T6364 | TERMINAL-BLADE (12-GA TO 16-GA) | 32 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(26-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(85-CM) | ||
| 1809340 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 248 | |
| 2V3726 | 10 BUMPER | 1 | |
| 4B4863 | 11 WASHER (4.7X11X1.2-MM THK) | 72 | |
| 5C2890 | 12 NUT (M6X1-THD) | 3 | |
| 5C9553 | 13 BOLT (M6X1X16-MM) | 3 | |
| 6D3031 | 14 SCREW-SOCKET HEAD (8-32X0.375-IN) | 34 | |
| 6D5801 | 15 LOCKNUT (8-32-THD) | 2 | |
| 6T3643 | 16 CIRCUIT BREAKER AS (15-AMPERE) | 11 | |
| 6T3644 | 17 CIRCUIT BREAKER AS (20-AMPERE) | 5 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 7K1181 | 18 STRAP-CABLE | 2 | |
| 9X8256 | 19 WASHER (6.6X12X2-MM THK) | 6 | |
| 9X8486 | 20 SCREW-MACHINE (8-32X0.75-IN) | 36 |
