Assembly
100%

426-3482 PANEL GP-CIRCUIT BREAKERS/N TFM283-UP

Group No: 426-3482
Part NumberPart NameQty
10546841 RELAY AS (24-VOLT)(DIODE)1
11579482 SOCKET-RELAY1
17292003 SUPPRESSOR-ARC1
22673004 CIRCUIT BREAKER AS (25-AMPERE)(HID LIGHTS, WARNING BEACON)1
9B7233LOCKWASHER2
6V8376SCREW-MACHINE (8-32X0.25-IN)2
23608725 STRAP AS14
28068346 WIRE AS (6-GA)1
29279437 PANEL AS-CIRCUIT BREAKER1
36365308 RELAY AS (24-VOLT)(EMERGENCY STOP)1
36365308A RELAY AS (24-VOLT)(FUEL PUMP)1
36365308B RELAY AS (24-VOLT)(PARKING LIGHTS)1
36365308C RELAY AS (24-VOLT)(WORK LIGHTS)1
36365308D RELAY AS (24-VOLT)(ROADING LIGHTS)1
36365308E RELAY AS (24-VOLT)(BRAKE LIGHTS)1
36365308F RELAY AS (24-VOLT)(TURN SIGNAL, LH)1
36365308G RELAY AS (24-VOLT)(TURN SIGNAL, RH)1
41624949 HARNESS AS-CONTROL1
419160510 SPRING-HOLDER1
2V372611 BUMPER1
4B486312 WASHER (4.7X11X1.2-MM THK)72
5C289013 NUT (M6X1-THD)3
5C955314 BOLT (M6X1X16-MM)3
6D303115 SCREW-SOCKET HEAD (8-32X0.375-IN)34
6D580116 LOCKNUT (8-32-THD)2
6T364317 CIRCUIT BREAKER AS (15-AMPERE)11
6T364418 CIRCUIT BREAKER AS (20-AMPERE)5
9B7233LOCKWASHER2
6V8376SCREW-MACHINE (8-32X0.25-IN)2
7K118119 STRAP-CABLE2
9X825620 WASHER (6.6X12X2-MM THK)6
9X848621 SCREW-MACHINE (8-32X0.75-IN)36
