198-8279 SENSOR GP-AUGERS/N TFM1-UP

Group No: 198-8279

Part Number	Part Name	Qty
2F7888	1 SCREW-MACHINE (10-32X1.25-IN)	4
4B1282	2 SCREW-MACHINE (1/4-20X0.75-IN)	4
5D3546	3 COLLAR	2
6B4540	4 NUT (4-40-THD)	6
6P6256	5 RETAINER-SPRING	2
6T8387	6 BEARING	2
6T8388	7 FLANGE	4
7D9708	8 BOLT-SPECIAL	2
8C8267	9 ROD-SENSOR	2
2392111	10 CABLE AS-COILED	2
2377508	LINK	1
2418153	PLUG AS	2
0951267	11 SETSCREW-SOCKET (M10X1.5-THD)	2
1162807	12 KNOB	2
1290844	13 PADDLE AS	2
2661480	14 SENSOR GP-POSITION (ROTARY)	2
1660691	15 BLOCK AS-MOUNTING (POSITION SENSOR)	2
1679664	16 PLATE	2
3667856	17 ARM (AUGER)	2
1992888	18 COVER	2
1994165	19 SHAFT	2
1995112	20 SUPPORT AS	2
8T9377	BOLT (3/8-16X2.25-IN)	1
4B4274	21 WASHER (5.5X13X1.2-MM THK)	4
5C2890	22 NUT (M6X1-THD)	4
5C7261	23 NUT (M8X1.25-THD)	4
5C9553	24 BOLT (M6X1X16-MM)	4
6V0894	25 SEAL-O-RING	2
6V2480	26 SCREW (4-40X0.5-IN)	6
8T4133	27 NUT (M10X1.5-THD)	4
8T4136	28 BOLT (M10X1.5X25-MM)	4
8T4191	29 BOLT (M10X1.5X16-MM)	4
8T4205	30 WASHER-HARD (7.2X14.5X2-MM THK)	8
8T4224	31 WASHER-HARD (8.8X16X2-MM THK)	10
8T4896	32 WASHER-HARD (10.2X18.5X2.5-MM THK)	6
8T7547	33 BOLT (M8X1.25X30-MM)	4
9B1117	34 LOCKWASHER	6
