System And Components
234-2637 STARTING MOTOR GP-ELECTRICS/N C6E1-UP
Group No: 234-2637
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X1279 | 1 CASE AS-STARTING MOTOR | 1 | |
| 9X1280 | 2 ARMATURE AS | 1 | |
| 2425441 | 3 DRIVE AS-STARTING MOTOR | 1 | |
| 2425443 | 4 HOUSING-STARTING MOTOR | 1 | |
| 2425444 | 5 SWITCH AS (STARTER) | 1 | |
| 9X1275 | 6 HOLDER AS-BRUSH | 1 | |
| 2425445 | 7 FRAME-STARTER | 1 | |
| 8J4455 | 8 BALL | 1 | |
| 7T6090 | 9 SPRING | 1 | |
| 9X1278 | 10 BOOT | 1 | |
| 7T6087 | 11 WASHER (15.2X40X0.5-MM THK) | 1 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 13 NUT (M10X1.5-THD) | 2 | |
| 9X2036 | 14 SCREW-PAN HEAD | 1 | |
| 3E5153 | 15 COVER-STARTING MOTOR | 1 | |
| 8C9778 | 16 PLUNGER AS | 1 | |
| 2425442 | 17 COVER-STARTER | 1 | |
| 3E5154 | 18 BUSHING-STARTING MOTOR | 1 | |
| 1003685 | 19 CAP | 1 | |
| 2P8104 | 20 BEARING | 1 | |
| 8L4070 | 21 BALL BEARING | 1 | |
| 8F1434 | 22 LOCKWASHER | 1 | |
| 9X1282 | KIT-STARTING MOTOR GEAR | 1 | |
| 9X1283 | KIT-HARDWARE (STARTING MOTOR) | 1 | |
| 9X1284 | KIT-STARTING MOTOR SEAL | 1 | |
| 9X1285 | KIT-BRUSH (STARTING MOTOR) | 1 |
