System And Components
304-9103 WIRING GP-HEATER -LHS/N TFM200-UP
Group No: 304-9103
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1160118 | 1 CLIP | 1 | |
| 8T4224 | 2 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 2895816 | 3 BOX GP-JUNCTION | 1 | |
| 8T0328 | 4 WASHER-HARD (5.5X10X1-MM THK) | 4 | |
| 3097501 | 5 HARNESS AS-WIRING (LH) | 1 | |
| 3148916 | 6 CABLE AS-POWER | 1 | |
| 1297163 | PLUG AS-CONNECTOR (1-PIN) | 2 | |
| 1148843 | SLEEVE-PLASTIC (40-CM) | ||
| 8N1541 | SOCKET-CONNECTOR (12-GA TO 14-GA) | 2 | |
| 8T2225 | TUBE-HEAT SHRINK (25.4-MM DIA)(10-CM) | ||
| 1305300 | 7 CLIP | 6 | |
| 7I2273 | 8 BOLT (M5X0.8X16-MM) | 2 | |
| 5C2874 | 9 NUT (M5X0.8-THD) | 2 | |
| 6V5217 | 10 BOLT (M8X1.25X20-MM) | 2 | |
| 7F6998 | 11 LOCKWASHER | 2 | |
| 1013917 | 12 WASHER (10.5X21X2-MM THK) | 3 | |
| 8T4133 | 13 NUT (M10X1.5-THD) | 1 | |
| 6V8212 | 14 BOLT (M10X1.5X16-MM) | 1 |
