272-7057 WIRING GP-MACHINE -RHS/N TFM1-UP

Group No: 272-7057

Part Number	Part Name	Qty
2727058	1 HARNESS AS-CHASSIS (RH)	1
1552260	KIT-CONNECTING PLUG (3-PIN)	2
1552270	KIT-CONNECTING PLUG (2-PIN)	11
1552271	KIT-CONNECTING PLUG (4-PIN)	2
1028802	KIT-RECEPTACLE (2-PIN)	4
1028803	KIT-RECEPTACLE (3-PIN)	2
1028804	KIT-RECEPTACLE (4-PIN)	1
7R7029	CONNECTOR-RECEPTACLE (6-PIN)	1
8T8737	PLUG-SEAL	35
1257875	TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM)
7N7978	TERMINAL-FORK (10-GA TO 12-GA, NO. 6 SCREW)	2
5P2321	TERMINAL-FORK (14-GA TO 16-GA, NO. 6 SCREW)	1
1311492	TERMINAL AS-RING (6-GA TO 8-GA)	1
2L8071	TERMINAL-RING (10-GA TO 12-GA, 1/2-IN SCREW)	3
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	24
1809340	SOCKET-CONNECTOR (14-GA TO 18-GA)	35
1835785	RECEPTACLE AS (40-PIN)	1
1123101	2 PLATE-FACE	1
7K1181	3 STRAP-CABLE	20
8T4137	4 BOLT (M10X1.5X20-MM)	1
3S2093	5 STRAP-CABLE	32
1893158	6 SUPPRESSOR-ARC	2
8T4200	7 BOLT (M8X1.25X16-MM)	1
5P4116	8 WASHER-HARD (8.8X20.5X2-MM THK)	1
1305300	9 CLIP	5
9G0011	10 SWITCH AS-TOGGLE (FLOW CONTROL)	1
6T3631	NUT-HEX (15/32-32-THD)	2
6V8374	SCREW-MACHINE (6-32X0.25-IN)	3
3L8187	LOCKWASHER	3
6T3632	LOCKWASHER	1
6T3633	RING-LOCKING	1
5D7635	11 GROMMET	1
8T4223	12 WASHER-HARD (13.5X25.5X3-MM THK)	2
8T4244	13 NUT (M12X1.75-THD)	2
4B4274	14 WASHER (5.5X13X1.2-MM THK)	3
2N3480	15 SCREW-MACHINE (10-24X0.75-IN)	3
4B2047	16 NUT (10-24-THD)	3
5C8312	17 NUT (M4X0.7-THD)	4
0966166	18 WASHER-HARD (4.5X9X1-MM THK)	4
6V9672	19 SCREW-MACHINE (M4X0.7X16-MM)	4
7G7053	20 GROMMET	3
8T4186	21 BOLT (M10X1.5X40-MM)	1
8T4121	22 WASHER-HARD (11X21X2.5-MM THK)	5
1160118	23 CLIP (SLOT)	1
9R5383	24 BOSS	1
2200230	25 ALARM AS (BACKUP)	1
9X1813	SLEEVE (29-CM)
1028802	KIT-RECEPTACLE (2-PIN)	1
5P5623	WIRE-ELECTRICAL (16-GA, BLACK)(0.8-M)
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	2
7X2621	26 BOLT (M10X1.5X12-MM)	2
6V9671	27 SCREW-MACHINE (M3X0.5X12-MM)	4
9B1117	28 LOCKWASHER	4
3C6969	29 NUT (M3X0.5-THD)	4
8D9537	30 CAP-DUST	1
1566175	31 CLIP (LADDER)	1
8T4133	32 NUT (M10X1.5-THD)	1
8T4191	33 BOLT (M10X1.5X16-MM)	1
